ShenZhen GETECH CO.,LTD
GEEETECH
Step 5.Tighten the wing nut (#12) to to reduce the slack in the timing belt (#36).
Repeat the above steps for the other 2 timing belts (#36).
Videos
8 Connect the Diagonal Rod to the carriage
Name
Part #
Qty.
Round head screw with pad
#15
6
www.geeetech.com
Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 – 858
Page
56
