*Note: Do not screw it too tightly as it may restrict the free movement of the drive
wheel. It is important that you leave enough room for the wheel to turn
freely.
Repeat these steps to assemble the other two drive wheel assemblies.
Step 4. Fix the drive wheel assembly loosely on the top plate (#A1) with a wing
nut (#12).
Repeat these steps to mount the other two drive wheel assemblies to the top plate
(#A1).

7.2 Add the belt

Name
Timing Belt
M3 x8 Screw
www.geeetech.com
ShenZhen GETECH CO.,LTD
GEEETECH
Part #
#36
#18
Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 – 858
Qty. Picture
3
6
