Mount The Smooth Rods - Geeetech Delta Rostock mini G2 pro Building Instruction

Step 1. Mount the hotend (#57) on the now assembled spider (#M1) with 2 M4 x
16 screws (#25).
*Note: Mounting of the single and double hot-ends are done exactly the same
way.
Videos

5 Mount the smooth rods

Name
Smooth Rod
www.geeetech.com
ShenZhen GETECH CO.,LTD
GEEETECH
Part #
#1
Tel: +86 755 2658 4110 Fax: +86 755 2658 4074 – 858
Qty.
6
Page 42
