Contents
Preparing for installation ···································································· 1
Safety recommendations ············································································································· 1
General safety recommendations ··························································································· 1
Electricity safety ·················································································································· 1
Handling safety ··················································································································· 1
ESD prevention ··················································································································· 2
Laser safety ······················································································································· 2
Examining the installation site ······································································································· 2
Weight support ··················································································································· 2
Temperature ······················································································································ 2
Humidity ···························································································································· 2
Cleanliness ························································································································ 3
EMI ·································································································································· 3
Grounding ·························································································································· 4
Power ······························································································································· 4
Cooling ····························································································································· 4
Space ······························································································································· 5
Installation tools ························································································································· 6
Installing the gateway ········································································ 8
Confirming installation preparations ······························································································· 8
Attaching slide rails to the rack ······································································································ 8
Installing cage nuts for attaching mounting brackets ································································· 11
Attaching cable management brackets and mounting brackets to the chassis ······································· 11
Installing cable management brackets ··················································································· 11
Installing mounting brackets ································································································ 13
(Optional) Installing air filters ······································································································ 13
Attaching air filters to an M9006/M9014 gateway ······································································ 14
Attaching air filters to an M9010/M9010-GM gateway ································································ 14
Mounting the gateway in the rack ································································································ 15
Grounding the gateway ············································································································· 16
Installing FRUs ························································································································ 17
Attaching an ESD wrist strap ······························································································· 17
Installing a card ················································································································· 18
Installing a power module ···································································································· 19
Installing an XFP/SFP+/SFP/QSFP+ transceiver module ··························································· 20
Installing a CFP module ······································································································ 21
Connecting networking cables ···································································································· 21
Connecting twisted pair cables ····························································································· 21
Connecting optical fibers ····································································································· 22
Connecting power cords ············································································································ 22
Connecting an AC power cord ······························································································ 23
Connecting a DC power cord ······························································································· 23
Logging in to the gateway and configuring basic settings ························ 24
Logging in through the console port ····························································································· 24
Setting up the configuration environment ················································································ 24
Setting terminal parameters ································································································· 25
Powering on the gateway ···································································································· 27
Logging in using Telnet ············································································································· 28
Verifying the network configuration ························································································ 28
Troubleshooting ············································································· 30
Troubleshooting methods ·········································································································· 30
Configuration terminal issues ······································································································ 30
No terminal display ············································································································ 30
Garbled terminal display ····································································································· 31
i
Advertisement
Table of Contents
Related Manuals for H3C SecPath M9000 Series
Summary of Contents for H3C SecPath M9000 Series
-
Page 1: Table Of Contents
Contents Preparing for installation ···································································· 1 Safety recommendations ············································································································· 1 General safety recommendations ··························································································· 1 Electricity safety ·················································································································· 1 Handling safety ··················································································································· 1 ESD prevention ··················································································································· 2 Laser safety ······················································································································· 2 Examining the installation site ······································································································· 2 ... - Page 2 Power supply system failure ······································································································· 31 Fan failure ······························································································································ 32 MPU failure ···························································································································· 32 Interface module, service module, or switching fabric module failure ··················································· 32 Interface failure ······················································································································· 33 Replacing FRUs ············································································· 34 Replacing a power module ········································································································· 34 ...
- Page 3 Interface numbering·················································································································· 68 Example ·························································································································· 68 Appendix E Cables ········································································· 70 Console cable ························································································································· 70 Ethernet twisted pair cable ········································································································· 70 RJ-45 connector ················································································································ 70 Cable pinouts ··················································································································· 71 Cable type ······················································································································· 71 ...
-
Page 4: Preparing For Installation
Preparing for installation The H3C SecPath M9000 Multi Service Security Gateway Series includes the following models: • M9006. • M9010. • M9010-GM. • M9014. Safety recommendations To avoid bodily injury and equipment damage, read all safety recommendations carefully before installation. Note that the recommendations do not cover every possible hazardous condition. -
Page 5: Esd Prevention
ESD prevention To prevent the electric component from being damaged by electrostatic discharge (ESD), follow these guidelines: • Ground the gateway correctly. For how to ground your gateway, see "Grounding the gateway." • Always wear an ESD wrist strap and make sure it is correctly grounded when installing FRUs. For how to use an ESD wrist strap, see "Attaching an ESD wrist strap."... -
Page 6: Cleanliness
• Lasting low relative humidity is likely to result in loose screws due to washer contraction, and even electrostatic discharge (ESD), which causes the circuits to fail. Table 2 Humidity requirements Humidity Range Operating humidity 10% to 95%, noncondensing Storage humidity 5% to 95%, noncondensing Cleanliness Dust buildup on the chassis might result in electrostatic adsorption, which causes poor contact of... -
Page 7: Grounding
• Keep the gateway far away from radio transmitting stations, radar stations, and high-frequency devices to make sure the EMI levels do not exceed the compliant range. • Use electromagnetic shielding, for example, shielded interface cables, when necessary. Grounding Using a good grounding system to protect your gateway against lightning shocks, interferences, and ESD is essential to the operating reliability of your gateway. -
Page 8: Space
Figure 1 Airflow through the M9010/M9010-GM chassis (1) Power module air inlet (2) Power module air outlet (3) Chassis air inlet (4) Chassis air outlet Figure 2 Airflow through the M9006 chassis (1) Power module air inlet (2) Power module air outlet (3) Chassis air inlet (4) Chassis air outlet Space... -
Page 9: Installation Tools
• The equipment room is at least 3 m (9.84 ft) high. • Reserve a minimum of 1 m (3.28 ft) of clearance between the rack and walls or other devices. • The dimensions of the rack are sufficient for the chassis. For more information about chassis specifications, see "Appendix A Chassis views and technical specifications."... - Page 10 Category Tool • Flat-blade screwdriver P4-75 mm • Phillips screwdriver P1-100 mm, P2-150 mm, and P3-250 mm Fastening tools • Socket wrench M5 • Socket wrench M6 Needle-nose pliers, diagonal pliers, combination pliers, wire-stripping pliers, crimping Small tools pliers, RJ-45 crimping pliers, file, and handsaw ESD wrist strap, hair brush, tweezers, paper knife, hand bellows, electric iron, solder wire, Auxiliary tools ladder, cable stripper, vacuum cleaner, crowbar, and rubber hammer...
-
Page 11: Installing The Gateway
"Appendix A Chassis views and technical specifications." As a best practice, order H3C slide rail LSTM2KSGD0. The slide rail has an adjustment range of 500 mm (19.69 in) to 800 mm (31.50 in). Slide rail installation varies by rack type. The following installation procedure is for your reference only. - Page 12 Figure 3 Right slide rail 1RU (Rack Unit) = 44.45 mm (1.75 in) (1) Guide rail (2) Sign (3) Installation hole Table 7 Description of signs on the slide rails Sign Meaning Remarks Front end of the left slide rail Mount this end to the front left rack post.
- Page 13 Figure 4 Locating the cage nut installation positions on the rack post (1) Middle of the narrower metal area between holes Install six cage nuts in the square holes on each rack post, as shown in Figure Figure 5 Installing a cage nut Align the installation holes on the front end of the slide rail with the cage nuts on the front rack post, and attach them with screws, as shown in Figure...
-
Page 14: Installing Cage Nuts For Attaching Mounting Brackets
Repeat steps 4 and 5 to install the other slide rail. Make sure the two slide rails are at the same height so that the gateway can be placed on them horizontally. Installing cage nuts for attaching mounting brackets Align the bottom edge of a mounting bracket with the weight-bearing surface of a slide rail. Determine and mark the cage nut installation holes on the rack post. - Page 15 The power cord management bracket installation procedure for the M9014, M9010, and M9010-GM is the same. To install a cable management bracket: Unpack the cable management bracket from the accessory kit package. Place the cable management bracket against the installation position on the chassis, and align the screws with the mounting holes on the chassis, as shown in Figure Fasten the screws to secure the cable management bracket to the chassis.
-
Page 16: Installing Mounting Brackets
Figure 9 Attaching the power cord management bracket to an M9006 gateway (1) Place the cable management bracket against the installation position on the chassis (2) Screw holes for installing the cable management bracket (3) Screws for attaching the cable management bracket to the chassis (4) Power cord management bracket Installing mounting brackets Before installing the gateway to the rack, install the mounting brackets to the chassis. -
Page 17: Attaching Air Filters To An M9006/M9014 Gateway
Attaching air filters to an M9006/M9014 gateway Air filters of an M9006/M9014 gateway are installed at the left of the chassis. The air filter installation procedures on an M9006 and M9014 are the same. To install an air filter on an M9006/M9014 gateway: Put the air filter near the air inlet vents on the left of the chassis and insert the poisoning pins on the air filter into the corresponding holes on the chassis. -
Page 18: Mounting The Gateway In The Rack
Figure 12 Attaching an air filter to an M9010/M9010-GM gateway TIP: • Install the power cord management bracket before you install an air filter for the M9010 or M9010-GM gateway. • Clean the air filter every three months to ensure correct ventilation and heat dissipation of the gateway. -
Page 19: Grounding The Gateway
Figure 13 Placing the chassis on the rack (M9006) Use the screws to attach the mounting brackets to the rack. If the mounting holes in the mounting brackets cannot align with the cage nuts on the rack, verify that the bottom edge of the slide rail aligns with the middle of the narrower metal area between holes and that the cage nuts are installed in the correct holes. -
Page 20: Installing Frus
Use the grounding screws to attach the two-hole grounding lug of the grounding cable to the chassis. Remove the grounding screw from the grounding hole of the cabinet's grounding terminal. Use the grounding screw to attach the ring terminal of the grounding cable to the grounding terminal of the cabinet. -
Page 21: Installing A Card
Installing a card IMPORTANT: • The gateway comes with no blank filler panels on some card slots. The figures in this document are for illustration only. • The switching fabric modules of the M9010, M9010-GM, and M9014 have protection boxes when shipped. -
Page 22: Installing A Power Module
Installing a power module CAUTION: • Do not install AC power modules and DC power modules on the same gateway. • Select power modules according to the power supply at the installation site. • Provide a circuit breaker for each power module and make sure the circuit breaker is off before installing the power module. -
Page 23: Installing An Xfp/Sfp+/Sfp/Qsfp+ Transceiver Module
Figure 19 Installing a power module in a horizontal slot (M9006) Installing an XFP/SFP+/SFP/QSFP+ transceiver module CAUTION: • To avoid component damage, read this section carefully before installing a transceiver module. • Do not remove the dust plug from a transceiver module before connecting an optical fiber. •... -
Page 24: Installing A Cfp Module
Installing a CFP module CAUTION: • Read the following instructions before installing a CFP module. Failure to follow these instructions might cause damage to the CFP module. • Do not remove the dust plug from the CFP module before connecting an optical fiber. •... -
Page 25: Connecting Optical Fibers
Connecting optical fibers WARNING! To avoid injury to your eyes, do not stare at the optical ports and optical fiber connectors when connecting optical fibers. You can install a transceiver module (see "Installing an XFP/SFP+/SFP/QSFP+ transceiver module Installing a CFP module") in a fiber port and use optical fibers to connect the port to the network. -
Page 26: Connecting An Ac Power Cord
Connecting an AC power cord Insert the power cord plug into the power receptacle of the power module. Use a cable tie to secure the power cord to the cable management bracket. Plug the other end of the power cord to the AC power receptacle of the power source. Figure 23 Securing the AC power cord (M9006) Connecting a DC power cord Insert the power cord plug into the power receptacle of the power module. -
Page 27: Logging In To The Gateway And Configuring Basic Settings
Logging in to the gateway and configuring basic settings The first time you access a gateway you must log in through the console port. After login, you can configure Telnet or SSH for remote access through Ethernet ports. For more information about login methods, see configuration guides that come with your gateway. -
Page 28: Setting Terminal Parameters
Setting terminal parameters To configure and manage the gateway, you must run a terminal emulator program on the console terminal. If your PC runs Windows 2003 Server, add the HyperTerminal component before performing the following steps to log in to and manage the gateway. If your PC runs Windows 2008 server, Windows 7, Windows Vista, or any other operating system, prepare third-party terminal control software, and follow the software user guide or help to configure the terminal. - Page 29 Figure 27 Setting the serial port used by the HyperTerminal connection Set Bits per second to 9600, Data bits to 8, Parity to None, Stop bits to 1, and Flow control to None, and click OK. To restore the default settings, click Restore Defaults. Figure 28 Setting the serial port parameters Select File >...
-
Page 30: Powering On The Gateway
Figure 29 HyperTerminal window On the Settings tab, set the emulation to VT100 and click OK. Figure 30 Setting terminal emulation in Gateway Properties dialog box Powering on the gateway Before power-on Before powering on the gateway, confirm the following:... -
Page 31: Logging In Using Telnet
• The gateway has been securely mounted. • All the cards have been correctly installed. • The unused slots have been installed with blank filler panels. • All the network cables, fibers, power cables, and grounding cables have been correctly connected. - Page 32 Task Command Display the current CPU usage statistics. display cpu-usage Display the current configuration of the gateway. display current-configuration Display device information. display device Display the temperature statistics about the device. display environment Display the operating states of fans. display fan Display interface brief information.
-
Page 33: Troubleshooting
MPUs, interface modules, and service modules, see "Appendix C LEDs." If you cannot locate failures by following the guidelines in this chapter, contact H3C Support. Configuration terminal issues If the configuration environment setup is correct, the configuration terminal displays boot information when the gateway is powered on. -
Page 34: Garbled Terminal Display
Flow control—None. When you modify the settings for the console port of the gateway, configure the same settings for the console terminal. If the issue persists, contact H3C Support. Power supply system failure Symptom The power LEDs are off or not green. -
Page 35: Fan Failure
Verify that the fan tray is fully seated. You can remove the fan tray and then install it again. Verify that the empty interface module slots and power module slots are installed with filler panels. If not, install filler panels for them to guarantee good ventilation. If the issue persists, contact H3C Support. MPU failure Symptom The RUN LED is off. -
Page 36: Interface Failure
If the gateway has empty card slots, plug the card into an empty card slot, and verify that the card can operate correctly. If the issue persists, contact H3C Support. Interface failure Symptom The LED of an interface connected to the network is off. -
Page 37: Replacing Frus
Replacing FRUs CAUTION: • When replacing FRUs while the gateway is running, be aware of electrical safety hazards. • Strictly follow the replacement procedures provided in this chapter to avoid device damage or bodily injury. • Wear an ESD wrist strap during the replacement and make sure the wrist strap has a good skin contact and is correctly grounded. -
Page 38: Replacing A Card
Put the removed power module on the antistatic mat. Install a new power module. For the installation procedures, see "Installing a power module." If no new power module is to be installed, install a blank filler panel to ensure adequate ventilation and dust prevention. -
Page 39: Replacing A Fan Tray
Use one hand to slowly move the card outwards. Supporting the bottom of the card with the other hand, pull the card out of the slot along slide rails, as shown in callout 3 on Figure Put the removed card on the antistatic mat. Install a new card. -
Page 40: Removing A Fan Tray
Removing a fan tray CAUTION: To ensure normal ventilation, install a new fan tray within two minutes after removing the old one. To remove a fan tray: Prepare an antistatic mat to place the fan tray to be removed. Loosen the captive screws on the fan tray, as shown in callout 1 on Figure Hold the handle of the fan tray with one hand to gently pull the fan tray part way out of the chassis. -
Page 41: Installing A Fan Tray
Installing a fan tray Unpack the fan tray. Holding the handle of the fan tray with one hand and supporting bottom with the other, gently slide the fan tray along the guide rails into the slot until it is firmly secured in the slot. Fasten the captive screws on the fan tray. -
Page 42: Replacing A Transceiver Module
Replacing a transceiver module WARNING! When you install or remove a transceiver module: • Do not stare at the fibers to avoid hurting your eyes. • Do not touch the golden plating on the module. Make sure the optical transceiver modules at the two ends of an optical fiber are the same model. In case of limited space, you can use the supplied tweezers to install or remove a transceiver module as a best practice. -
Page 43: Appendix A Chassis Views And Technical Specifications
Appendix A Chassis views and technical specifications Chassis views Every M9000 gateway has an MPU section, interface module and service module section, switching fabric module section, power module section, and fan tray section. Figure 38 Front and rear views of the M9006... - Page 44 Figure 39 Front and rear views of the M9010 and M9010-GM...
- Page 45 Figure 40 Front and rear views of the M9014 Table 8 Chassis structure Section Description Remarks The chassis comes with no MPUs installed. You must install a minimum of one MPU for the (1) MPU slots chassis. The available MPU model is NSQ1SUPB0.
-
Page 46: Weights And Dimensions
Section Description Remarks The chassis comes with a fan tray in each fan • tray slot. You do not need to order fan trays. Located at the left rear of the The number of fan tray slots varies by device chassis for the M9006 and M9014 model: gateways. - Page 47 Card model Weight Height Width Depth NSQ1TGS32SF0 3.45 kg (7.61 lb) 40 mm (1.57 in) 399 mm (15.71 in) 352 mm (13.86 in) NSQ1QGS4SF0 3.14 kg (6.92 lb) 40 mm (1.57 in) 399 mm (15.71 in) 352 mm (13.86 in) NSQM1MBFEA0 2.9 kg (6.39 lb) 40 mm (1.57 in)
-
Page 48: Module Power Consumption And System Power Consumption
Table 11 Power module weights and dimensions Model Weight Height Width Depth NSQM1AC2500 2.5 kg (5.51 lb) 41 mm (1.61 in) 102 mm (4.02 in) 410 mm (16.14 in) NSQM1DC2400 2.4 kg (5.29 lb) 41 mm (1.61 in) 102 mm (4.02 in) 410 mm (16.14 in) Table 12 Fan tray weights and dimensions Fan tray... -
Page 49: Fan Tray Power Consumption
Minimum static power Maximum dynamic power Model consumption consumption NSQM1CGQ20 15 W 16 W NSQM2QG4GP40 16 W NSQM2QG2TG8GP40 19 W NSQM2QG2GP40 10 W NSQM2TG8GP40 12 W NSQ1FAB04B0 48 W 65 W NSQ1FAB08D0 101 W 135 W NSQ1FAB12D0 195 W 255 W NSQ1FWCEA0 109 W 157 W... -
Page 50: System Power Consumption
Minimum fan tray power Maximum fan tray power Model consumption consumption M9014 (lower fan tray) 124 W System power consumption The system power consumption of the gateway depends on the type and number of cards and the fan tray power consumption. •... -
Page 51: Service Modules
Service modules The services modules available for the M9000 security gateway are described in Table Table 17 Service module specifications Model Description Port Connector One console port RJ-45 10/100/1000BASE RJ-45 NSQ1FWCEA0 Firewall module -T copper port Two Gigabit combo interfaces 1000BASE-X SFP fiber port One console port... -
Page 52: Interface Modules
One console port RJ-45 Network data encryption NSQM1GMDSCA1 Two USB ports module One Gigabit copper combo port RJ-45 Interface modules The interface modules available for the M9000 gateway series are described in Table Table 18 Interface module specifications Interface Port Available Number module... -
Page 53: Interface Subcards
Interface Port Available Number module Description Connector transmission transceiver of ports model rate modules 2-port 100-Gigabit NSQ1CGC2 CFP optical 100-Gigabit CFP 100 Gbps Ethernet interface transceiver module module Gigabit SFP 32-port 10-Gigabit + 1 Gbps transceiver module NSQM1TGS 4-port 40-Gigabit 32QSSG0 optical Ethernet QSFP+ transceiver... -
Page 54: Interface Switch Modules
Interface Port Available Number subcard Description Connector transmission transceiver of ports model rate modules Gigabit SFP 1 Gbps transceiver module 4-port 1000BASE-X + 8-port 10-Gigabit SFP+ NSQM2QG2T 10GBASE-R + 10 Gbps transceiver G8GP40 2-port 40GBASE-R module optical interface module QSFP+ 40 Gbps transceiver module... -
Page 55: Environmental Specifications
For the power consumption of the cards and fan trays of the M9000 gateways, see "Module power consumption and system power consumption." Environmental specifications Table 21 Environmental specifications Description Operating Non-operating Temperature 0°C to 45°C (32°F to 113°F) –40°C to +70°C (–40°F to +158°F) Relative humidity 10% to 95% (non-condensing) 5% to 95% (non-condensing) -
Page 56: Appendix B Frus And Compatibility Matrixes
M9006 M9010 NSQ1SUPB0 M9010-GM M9014 For more information about the NSQ1SUPB0, see H3C SecPath M9000 NSQ1SUPB0 MPU Card Manual. Service modules The services modules available for the M9000 security gateway are described in Table Table 24 Service module and gateway compatibility... -
Page 57: Interface Modules
Interface modules The interface modules available for the M9000 gateway series are described in Table Table 25 Interface module and gateway compatibility Interface module model Applicable gateways NSQ1TGS8EA0 NSQ1GT48EA0 NSQ1GP24TXEA0 M9006 NSQ1TGX4EA0 M9010 NSQ1GP48EB0 M9010-GM NSQ1TGS32SF0 M9014 NSQ1QGS4SF0 NSQ1CGC2SE0 NSQM1TGS32QSSG0 For more information about the interface modules, see the card manuals that come with the interface modules. -
Page 58: Power Modules
Switching fabric module model Applicable gateways M9010 NSQ1FAB08D0 M9010-GM NSQ1FAB12D0 M9014 Power modules The gateway supports power modules of models NSQM1AC2500 and NSQM1DC2400. An NSQM1AC2500 power module is an AC-input, DC-output power module that provides a maximum DC output power of 2500 W. An NSQM1DC2400 power module is a DC-input, DC-output power module that provides a maximum DC output power of 2400 W. -
Page 59: Air Filters
Table 29 Fan tray specifications Number of Maximum Maximum air Fan tray Fan diameter fans rotating speed flow rate M9006 fan tray 92 mm (3.62 in) 6000 RPM 960 CFM M9010/M9010-GM 120 mm (4.72 in) 5200 RPM 1152 CFM fan tray M9014 upper fan tray 120 mm (4.72 in) 5200 RPM... - Page 60 • Select AC power cords according to the power of the power module. • The connector type varies by country or region. Select a compliant connector type as needed. • For the power module NSQM1AC2500, select 16A AC power cords. For the connector types of different countries or regions, see Table Table 31 16A AC power cords used in different countries or regions...
- Page 61 Countries or regions where the type of Countries or Other countries or regions power cords conforms regions seldom Connector Code (Length) using this type of power type to local safety using this type cords regulations and can of power cords be used legally Holland, Denmark, Sweden, Finland,...
- Page 62 Countries or regions where the type of Countries or Other countries or regions Connector power cords conforms regions seldom Code (Length) using this type of power type to local safety using this type cords regulations and can of power cords be used legally 0404A01A (3 I type...
-
Page 63: Appendix C Leds
Appendix C LEDs The M9000 gateway series provides a lot of LEDs. You can determine the gateway operating status by examining the LEDs. MPU LEDs Figure 41 shows the LEDs on the MPU. Figure 41 MPU LEDs (1) Management Ethernet port LEDs (2) Fan LEDs (3) Card status LEDs (4) MPU active/standby status LED... -
Page 64: Service Module Leds
NOTE: Slot numbers are marked on top of the slots on the M9010 and M9010-GM gateways and on the right of the slots on M9006 and M9014 gateways. Table 34 Card LED description Description Flashing The card is operating correctly. The card is loading software. -
Page 65: M1Ssicask1 Security Situation Intelligent Computer Node Module Leds
Status Description Fast flashing (8 Hz) The card is loading software or has not started. No link is present. LINK/ACT Steady green A link is present. Flashing The port is sending or receiving data. M1SSICASK1 security situation intelligent computer node module LEDs The NSQM1SSICASK1 security situation intelligent computer node module provides LEDs to indicate the operation status for the module and the hard disk. -
Page 66: Interface Module Leds
Table 38 LED description for other service modules except the NSQ1FWCEA0 Status Description The hard disk has failed or is not present. Hard disk LED Flashing green The hard disk is reading and writing data. (HD) Steady green The hard disk is operating correctly. No power is being input or the card is faulty. - Page 67 Table 41 SFP+ port LED description LED status Description Flashing yellow The port is receiving or sending data at 100/1000 Mbps. Flashing green The port is receiving or sending data at 10 Gbps. Steady yellow A 100/1000 Mbps link is present. Steady green A 10 Gbps link is present.
-
Page 68: Switching Fabric Module Leds
Table 45 100GBASE-R port LED description LED status Description Flashing The port is receiving or sending data. A link is present, but no data is being received or sent. No link is present. 1000BASE-X port LEDs The interface modules provide a LED for each 1000BASE-X port to indicate the link status and data receiving/forwarding status of the 1000BASE-X port. -
Page 69: Power Module Leds
Table 49 Fan tray LED description FAIL Description The fan tray is operating correctly. The fan tray is faulty. The fan tray is not powered on. Power module LEDs The NSQM1AC2500 power module for the M9000 gateways has one AC LED and one DC LED to indicate its operating status. -
Page 70: Appendix D Slot Arrangement And Interface Numbering
Appendix D Slot arrangement and interface numbering Card slot arrangement Figure 42 Card slot arrangement of the M9006, M9010/M9010-GM, and M9014 From left to right, Figure 42 shows the slot arrangement on the M9006, M9010/M9010-GM, and M9014 gateways. Table 52 Card slot arrangement Model Card slot arrangement Slot mark location... -
Page 71: Example
Example You can execute the display device command to view the slot arrangement on the device. <Sysname> display device Slot NO Brd Type Brd Status Subslot Sft Ver Patch Ver NSQM2PUCO Master M9006-9153P05 None Interface numbering The gateway provides many types of interfaces, including console, M-GigabitEthernet, GigabitEthernet, Ten-GigabitEthernet, Forty-GigabitEthernet, Hundred-GigabitEthernet, blade, aggregate, tunnel, Virtual-Template, and VLAN interfaces. - Page 72 <Sysname> display interface GigabitEthernet brief Brief information on interface(s) under route mode: Link: ADM - administratively down; Stby - standby Protocol: (s) - spoofing Interface Link Protocol Main IP Description GE1/2/0/1 DOWN DOWN 192.168.1.1 GE1/2/0/2 DOWN DOWN GE1/2/0/3 DOWN DOWN GE1/2/0/4 DOWN DOWN GE1/2/0/5...
-
Page 73: Appendix E Cables
Appendix E Cables This chapter describes cables used for connecting network ports. Table 53 Cable description Cable Port type Application RJ-45 Ethernet port at one Connects the console port of the gateway to Console cable end and DB-9 port at the the console terminal. -
Page 74: Cable Pinouts
Figure 44 RJ-45 connector pinout diagram PIN #8 PIN #1 Cable pinouts EIA/TIA cabling specifications define two standards: 568A and 568B for cable pinouts. • Standard 568A—pin 1: white/green stripe, pin 2: green solid, pin 3: white/orange stripe, pin 4: blue solid, pin 5: white/blue stripe, pin 6: orange solid, pin 7: white/brown stripe, pin 8: brown solid. -
Page 75: Pin Assignments
Figure 45 Straight-through cable Figure 46 Crossover cable Pin assignments Select an Ethernet twisted pair cable according to the RJ-45 Ethernet interface type on your device. An RJ-45 Ethernet interface can be MDI or MDIX. For the pinouts of RJ-45 Ethernet interfaces, Table 55 Table... -
Page 76: Making An Ethernet Twisted Pair Cable
Table 55 RJ-45 MDI interface pinouts 10Base-T/100Base-TX 1000Base-T Signal Function Signal Function Send data BIDA+ Bi-directional data cable A+ Send data BIDA- Bi-directional data cable A- Receive data BIDB+ Bi-directional data cable B+ Reserved BIDC+ Bi-directional data cable C+ Reserved BIDC- Bi-directional data cable C- Receive data... -
Page 77: Optical Fiber
Repeat the above steps with the other end of the cable. Use a cable tester to verify the connectivity of the cable. Optical fiber CAUTION: Use the same types of transceiver modules, pigtail cords, patch cords, and fiber cables. If you use single-mode optical fibers, the transceiver modules, pigtail cords, patch cords, and fiber cables must be single-mode. -
Page 78: Pigtail Cord
Pigtail cord A pigtail cord is an optical fiber that has an optical connector on one end and a length of exposed fiber on the other. The end of the pigtail is fusion spliced to a fiber, connecting the fiber cable and transceiver. -
Page 79: Precautions
Precautions • Make sure the fiber connector and fiber type match the transceiver module type. • The fiber ports on some cards have shielded covers. Remove the shielded covers before using the fiber ports. Fiber interfaces must be installed with shielded covers when they are not in use. Keep them safely. -
Page 80: Appendix F Cabling Recommendations
Appendix F Cabling recommendations When an M9000 gateway is mounted in a 19-inch standard rack, the interface cables are routed through the cable management brackets, bound at cabling racks on chassis sides, and then routed up or down to pass through the chassis top or the raised floor, depending on the available equipment room condition. - Page 81 Figure 50 Correct and incorrect cable binding • The cable bend radius at connectors must be at least 5 times the cable diameter, and must be at least twice the cable diameter away from the connectors. • Route different types of cables (for example, power cords and signal cables) separately. If they are close to one another, cross them over one another.
- Page 82 Figure 52 Binding cables where they must be bent • Route, bind, and attach excess cables for easy, safe maintenance activities and correct operations. • Do not tie power cords to slide rails. • When you connect a cable to an articulated part, for example, when you connect a grounding cable to a cabinet door, leave enough slack in cables and make sure they are not stressed from any movement of the part.
- Page 83 Table 58 Tie-binding parameters Cable bundle diameter (mm) Space between bundles (mm) 80 to 150 10 to 30 150 to 200 200 to 300 • Do not tie cables or bundles in a knot. • The metal parts of the crimped cold-pressed terminal blocks (such as circuit breaker) cannot protrude beyond the blocks.
-
Page 84: Appendix G Repackaging The Gateway
Appendix G Repackaging the gateway This chapter describes how to repackage the gateway chassis, power module, card, mounting bracket, cable management bracket, and air filter. Removing cables from the gateway Before repackaging the gateway, remove all cables such as the power cord, console cable, twisted pair, optical fiber, and grounding cable from the gateway. -
Page 85: Removing The Twisted Pair And Optical Fiber
Figure 54 Removing the grounding cable Removing the twisted pair and optical fiber You must remove twisted pairs and optical fibers from all the interfaces of the gateway. NOTE: After pulling out an optical fiber from an optical transceiver module, cover the connector of the optical fiber with a dust cap to keep the connector clean. -
Page 86: Repackaging The Card
Repackaging the card Prepare the anti-static bag and box of the card. Make sure the bag is clean, dry, and not damaged. Remove the transceiver modules from the card. If no transceiver module is installed on the card, go to the next step. For how to remove a transceiver module, see "Replacing a transceiver module."... -
Page 87: Removing The Air Filter
Figure 55 Removing the chassis (M9006) from the rack Put the chassis onto the pallet base of the wooden carton. Removing the air filter Prepare the packing bag of the air filter. Make sure the bag is clean, dry, and not damaged. Remove the air filter from the side of the chassis. - Page 88 Figure 56 Removing the mounting brackets from the chassis (M9006) Put the mounting brackets into the box. Removing the cable management brackets The M9010/M9010-GM gateway has two cable management brackets—the one on the chassis bottom routes power cords, and the one on the chassis top routes signal cables. The M9006/M9014 gateway provides a cable management bracket at the chassis bottom to route power cords.
-
Page 89: Repackaging The Gateway Chassis
Figure 57 Removing the cable management brackets (M9010) (1) Loosen the screws that attach the cable management brackets to the chassis (2) Remove the cable management brackets Repackaging the gateway chassis Align the screw holes on the two sides of the chassis bottom to the L-type brackets on the pallet base of the wooden carton. - Page 90 Figure 58 Installing the screws (M9010) Cover the chassis with the packing bag, and then tape the bag to the base pallet. Install the side panels to the base pallet. Put the accessories box and mounting bracket box into the wooden carton—at the clearance between the chassis and the wooden panel.
Need help?
Do you have a question about the SecPath M9000 Series and is the answer not in the manual?
Questions and answers
