H3C SecPath M9000-X Series Installation Manual

Hide thumbs Also See for SecPath M9000-X Series:

Installation, quick start (34 pages)

page of 76

/ 76
Bookmarks

Quick Links

Download this manual

H3C SecPath M9000-X[AI-X] Multiservice

Security Gateway Series

Installation Guide

No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of New

H3C Technologies Co., Ltd.

Except for the trademarks of New H3C Technologies Co., Ltd., any trademarks that may be mentioned in this document are

the property of their respective owners.

The information in this document is subject to change without notice.

Need help?

Do you have a question about the SecPath M9000-X Series and is the answer not in the manual?

Questions and answers

Summary of Contents for H3C SecPath M9000-X Series

Page 1 No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of New H3C Technologies Co., Ltd. Except for the trademarks of New H3C Technologies Co., Ltd., any trademarks that may be mentioned in this document are the property of their respective owners.
Page 2 Contents 1 Preparing for installation ·········································································· 1-1 Safety recommendations ································································································································ 1-1 Safety symbols ········································································································································ 1-1 General safety recommendations ··········································································································· 1-1 Electricity safety ······································································································································ 1-2 ESD prevention ······································································································································· 1-2 Laser safety ············································································································································· 1-2 Handling safety ······································································································································· 1-3 Installation site requirements ·························································································································· 1-3 Weight support ········································································································································...
Page 3 5 Troubleshooting ····················································································· 5-31 Troubleshooting methods······························································································································ 5-31 Configuration terminal issues ························································································································ 5-32 No terminal display ································································································································ 5-32 Garbled terminal display ······················································································································· 5-32 Power supply failure ······································································································································ 5-33 Fan tray failure ·············································································································································· 5-33 SEM failure···················································································································································· 5-34 Switching fabric module failure ····················································································································· 5-35 Interface switch module failure······················································································································...
Page 4 Repackaging the gateway ····························································································································· 9-58 Repackaging a power supply ················································································································ 9-58 Repackaging a module ························································································································· 9-58 (Optional.) Removing the air filter doors ······························································································· 9-59 Removing cable management brackets ································································································ 9-59 Removing the chassis from the rack ····································································································· 9-59 Repackaging the gateway chassis ········································································································ 9-60...
Page 5 Preparing for installation Safety recommendations To avoid bodily injury and device damage, read all safety recommendations carefully before installation. Note that the recommendations do not cover every possible hazardous condition. Safety symbols When reading this document, note the following symbols: WARNING means an alert that calls attention to important information that if not understood or followed can result in personal injury.
Page 6 • Ensure good ventilation of the equipment room and keep the air inlet and outlet vents of the gateway free of obstruction. • Make sure the power source voltage meets the requirements of the gateway. • Use a screwdriver, rather than your fingers, to fasten screws. •...
Page 7 • To ensure the correct operation of the gateway, make sure the room temperature and humidity meet the requirements. For more information, see the hardware information and specifications for the product on the H3C official website at https://www.h3c.com/en/Support/Resource_Center/Technical_Documents/Security/.
Page 8 Cleanliness Dust buildup on the chassis might result in electrostatic adsorption, which causes poor contact of metal components and contact points. In the worst case, electrostatic adsorption can cause communication failure. Table1-2 Dust concentration limit in the equipment room Substance Concentration limit (particles/m ≤...
Page 9 Figure1-1 Airflow through the chassis (M9000-X06 gateway) ESD prevention To prevent ESD, follow these guidelines: • Make sure the gateway, the workbench, and the rack are reliably grounded. • Take dust-proof measures for the equipment room. For more information, see "Cleanliness." •...
Page 10 For more information about the power supplies, see the hardware information specifications gateway official website https://www.h3c.com/en/Support/Resource_Center/Technical_Documents/Security/. Installation tools No installation tools are provided with the gateway. Prepare them yourself as required.
Page 11 This document lists the installation accessories required for all gateways. The required installation accessories vary by gateway model. For the installation accessories required by a gateway, see the hardware information and specifications for that gateway on the H3C official website at https://www.h3c.com/en/Support/Resource_Center/Technical_Documents/Security/.
Page 12 Pre-installation checklist Table1-4 Pre-installation checklist Item Requirements Result • There is a minimum clearance of 300 mm (11.81 in) around the inlet and outlet air vents. Ventilation • A good ventilation system is available at the installation site. For more information about the temperature Temperature requirements, see the hardware information and specifications for the product.
Page 13 Item Requirements Result is located so that the power can be immediately shut off when an accident occurs. • There is a minimum clear height of 3 m (9.84 ft) (from the beam or the air duct to the floor) in the equipment room.
Page 14 Keep the tamper-proof seal on a mounting screw on the chassis cover intact, and if you want to open the chassis, contact H3C for permission. Otherwise, H3C shall not be liable for any consequence. The installation method and accessories vary by gateway model. For more information about the...
Page 15 Mounting the gateway in a standard 19-inch rack Restrictions and guidelines CAUTION: • When you move the gateway to a low temperature environment from a high temperature environment, condensation might occur. Before installing the gateway, please dry the gateway to prevent the internal components from being damaged because of short circuit.
Page 16 Figure2-2 Installing the cage nuts Align the rear of the chassis with the front of the rack. Use multiple people to lift the gateway by holding the chassis handles. As a best practice, use a minimum of four people to lift a 12U gateway. Place the gateway on the slide rails from front of the rack.
Page 17 Figure2-4 Connecting the grounding cable to the gateway Installing modules CAUTION: • Before connecting the gateway to a power source, install all modules. • To fasten a captive screw for a module, make sure the screwdriver bit matches the screw. Set the fastening torque to 5.5 kgf-cm (0.54 Nm) ±...
Page 18 Figure2-5 Installing a SEM for a 6U gateway Installing a SEM for a 12U gateway Remove the filler panel from the target SEM slot. Keep the removed filler panel secure for future use. Correctly orient the SEM, and then push it steadily into the slot along the guide rails. Fully open the ejector levers of the SEM.
Page 19 6U gateway, slot 6 and slot 7 take precedence. Install H3C filler panels with a product code of 2113A3EM in empty switching fabric module slots. • The 12U gateway provides six switching fabric module slots, but only slots 10 to 13 are available.
Page 20 To install a switching fabric module: Face the rear panel of the gateway and remove the filler panel from the target slot. Keep the removed filler panel secure for future use. Figure2-7 Removing a switching fabric module filler model from an M9000-X06 gateway Press the locking tabs of the ejector levers to release the levers.
Page 21 Figure2-8 Installing a switching fabric module for an M9000-X06 gateway Installing interface modules or service modules CAUTION: • To install an interface module or service module on the gateway, first install it on an interface switch module and then install the interface switch module on the gateway. •...
Page 22 Figure2-9 Removing the filler panel Open the ejector lever on the interface module and then push the module slowly into the slot along the guide rails until you cannot push it any further. Close the ejector lever until the latch locks the ejector lever in place. Figure2-10 Installing an interface module on an interface switch module Install the interface switch module in the gateway.
Page 23 To install an interface switch module: Remove the filler panel from the target interface switch module slot. Keep the removed filler panel secure for future use. Figure2-11 Removing the filler panel Pivot down and fully open the ejector levers of the module. Gently push the module into the slot along the guide rails.
Page 24 Installing fan trays To install a fan tray in slot FAN1 on a 6U gateway, orient the fan tray with the LEDs to the left of the handle. To install a fan tray in slot FAN2, orient the fan tray with the LEDs to the right of the handle. To install a fan tray on a 12U gateway, orient the fan tray with the LEDs above the handle.
Page 25 Installing AC power supplies AC power supply configuration guidelines Determine the number of AC power supplies based on the system power consumption and the AC power supply configuration based on the power input mode.
Page 26 Installing an AC power supply Put your forefinger into the hole in the filler panel and pull out the filler panel along the guide rails. Figure2-15 Removing a filler panel Correctly orient the power supply. Align the power supply with the power supply slot. Then slide the power supply along the guide rails into the slot until the latch locks the power supply in place.
Page 27 Figure2-17 Connecting an AC power cord (M9000-X06 gateway) Installing DC power supplies DC power supply configuration guidelines Determine the number of DC power supplies based on the system power consumption and the DC power supply configuration based on the power input mode. •...
Page 28 Figure2-19 Installing a power supply Connecting a DC power cord WARNING! Before you connect a DC power cord, make sure the circuit breakers for both of the positive and negative power input wires are turned off. To connect a DC power cord: Connect the DC power cord connector to the DC input receptacle of the power supply.
Page 29 • Make sure the total output power of the power supplies is greater than the system power consumption (with a 20% power surplus as a best practice). • Provide a circuit breaker for power input of each HVDC power supply. Make sure each circuit breaker has a current rating not less than 20 A and meets the requirements for HVDC power supply, such as HVDC certification and bipolar protection.
Page 30 Figure2-21 Installing a transceiver module and fiber cable (with LC fiber connectors) Figure2-22 Installing a transceiver module and fiber cable (with an MPO fiber connector) Verifying the installation Table2-3 Post-installation checklist Item Requirements • No condensation on the surface of the gateway or inside of the gateway. •...
Page 31 Item Requirements • All modules are installed correctly. • No slot is empty. Each is installed with a module or filler panel, Gateway • Fan trays are installed correctly. • The gateway is grounded reliably with the provided grounding cable. Both ends of the grounding cable are securely connected.
Page 32 For more information about LEDs on a gateway, see the hardware information and specifications for that gateway official website https://www.h3c.com/en/Support/Resource_Center/Technical_Documents/Security/. Accessing the gateway CAUTION: • The command output varies by software version used by the device. • To access the EXTENDED-BOOTWARE menu, press Ctrl+B within 4 seconds at the prompt "Press Ctrl+B to access EXTENDED-BOOTWARE MENU."...
Page 33 No console cables are provided with the gateway. Prepare them yourself as required. The RJ-45 signal pinout varies by vendor of the cable. To avoid abnormal display on the configuration terminal, use a console cable provided by H3C (as shown in Table3-2). To prepare a 3-20...
Page 34 USB-to-RJ45 console driver on the configuration terminal, and then connect the USB-to-RJ45 console cable to the configuration terminal. To download the USB-to-RJ45 console driver, access the H3C official website or scan the QR code on the cable package.
Page 35 View the TXT file Read me in the Windows folder to check whether the Windows system of the configuration terminal supports the driver. If the Windows system supports the driver, install PL23XX-M_LogoDriver_Setup_v200_20190815.exe. Click Next on the welcome page of the driver installation wizard. Figure3-1 Driver installation wizard Click Finish after the driver installation is completed.
Page 36 Configure the baud rate as required. • For information about the default baud rate of ports on a gateway, see the hardware information and technical specifications for that gateway on the H3C official website at https://www.h3c.com/en/Support/Resource_Center/Technical_Documents/Security/. Powering on the gateway During the startup process, you can access Boot ROM menus to perform tasks such as software upgrade and file management.
Page 37 By default, the authentication mode is scheme, the username is admin, and the password is admin. The gateway is shipped with the default IP address of the management Ethernet port. Assign an IP address to the PC's network port and make sure the PC and gateway can reach each other.
Page 38 Figure4-1 Removing a SEM from an M9000-X06 gateway Replacing a SEM for a 12U gateway Prepare an antistatic mat for placing the removed SEM. Wear an ESD wrist strap, and make sure it makes good skin contact and is reliably grounded. Use a Phillips screwdriver to loosen the captive screws on the module.
Page 39 Replacing a switching fabric module CAUTION: The 12U gateway supports hot swapping of switching fabric modules. To replace a switching fabric module on an operating gateway, make sure a minimum of one switching fabric module is operating correctly and finish replacing the switching fabric module within 2 minutes. To replace a switching fabric module: Prepare an antistatic mat for placing the removed switching fabric module.
Page 40 Figure4-4 Removing an interface switch module (M9000-X06 gateway) Replacing an interface module or service module The replacement procedure is the same for service modules and interface modules. The following uses an interface module as an example. To replace an interface module: Prepare an antistatic mat for placing the removed interface module.
Page 41 Replacing a transceiver module WARNING! • Disconnected optical fibers or transceiver modules might emit invisible laser light. Do not stare into beams or view directly with optical instruments when the gateway is operating. CAUTION: • Do not touch the golden plating on a transceiver module. •...
Page 42 Figure4-7 Removing a transceiver module (MPO port) Replacing a fan tray WARNING! • Ensure electricity safety when you hot swap a fan tray. • To avoid bodily injury, do not touch the spinning fans when you replace the fan tray. •...
Page 43 Figure4-8 Removing a fan tray (M9000-X06 gateway) Replacing a power supply WARNING! • Provide a circuit breaker for each power supply. Before replacing a power supply, turn off the circuit breaker for it. • To reinstall the removed power supply in the chassis, wait until the status LEDs on it are off. •...
Page 44 The SEM provides LEDs for the fan trays, power supplies, and modules. You can locate the failures according to the LED status on the SEM. For more information about the status of LEDs on the SEM, see the hardware information and technical specifications for the gateway on the H3C official website at https://www.h3c.com/en/Support/Resource_Center/Technical_Documents/Security/. •...
Page 45 If any configuration error is found, re-configure the gateway or restore the factory-default settings. If you cannot locate failures by following the guidelines in this chapter, contact H3C Support. Configuration terminal issues If the configuration environment setup is correct, the configuration terminal displays boot information when the gateway is powered on.
Page 46 If the new power supply can operate correctly, the old power supply has failed. You must replace the old power supply. If the issue persists, contact H3C Support. NOTE: After you turn off the power feed to a power supply, the input and output status LEDs on the power supply will stay on for a while.
Page 47 Verify that the fan tray is fully seated. You can remove the fan tray and then install it again. Verify that the empty module slots and power supply slots are installed with filler panels. If not, install filler panels for them to guarantee good ventilation. If the issue persists, contact H3C Support. SEM failure Symptom •...
Page 48 SEM is fully seated. Press the RESET button of the SEM to reset the SEM. After the SEM is reset, verify that the ACTIVE LED is on. If the issue persists, contact H3C Support. Switching fabric module failure Symptom The RUN/ALM LED on a switching fabric module is steady red.
Page 49 Verify that the speed and duplex settings of the ports of a link are the same. Make sure two ports can work together. If the issue persists, contact H3C Support. Cables This chapter describes cables used for connecting network ports.
Page 50 Figure6-2 Console cable (DB9-to-RJ45 console cable as an example) Table6-2 RJ-45 connector pinout RJ-45 Signal DB-9 Signal Ethernet twisted pair cable An Ethernet twisted pair cable consists of four pairs of insulated wires twisted together. It mainly transmits analog signals and is advantageous in transmitting data over shorter distances. The maximum transmission distance is 100 m (328.08 ft).
Page 51 Cable pinouts EIA/TIA cabling specifications define two standards: 568A and 568B for cable pinouts. • Standard 568A—pin 1: white/green stripe, pin 2: green solid, pin 3: white/orange stripe, pin 4: blue solid, pin 5: white/blue stripe, pin 6: orange solid, pin 7: white/brown stripe, pin 8: brown solid.
Page 52 Figure6-4 Straight-through cable white/orange orange white/green blue white/blue green white/brown brown Straight-through cable white/orange orange white/green blue white/blue green white/brown brown Figure6-5 Crossover cable white/orange orange white/green blue white/blue green white/brown brown Crossover cable white/green green white/orange blue white/blue orange white/brown brown Pin assignments...
Page 53 Table6-4 RJ-45 MDI port pinouts 10Base-T/100Base-TX 1000Base-T Signal Function Signal Function Sends data BIDA+ Bi-directional data cable A+ Sends data BIDA- Bi-directional data cable A- Receives data BIDB+ Bi-directional data cable B+ Reserved BIDC+ Bi-directional data cable C+ Reserved BIDC- Bi-directional data cable C- Receives data BIDB-...
Page 54 Repeat the above steps with the other end of the cable. Use a cable tester to verify the connectivity of the cable. Optical fiber CAUTION: Use the same types of transceiver modules, pigtail cords, patch cords, and fiber cables. If you use single-mode optical fibers, the transceiver modules, pigtail cords, patch cords, and fiber cables must be single-mode.
Page 55 Pigtail cords fall into single-mode (yellow) and multimode (orange), and can also be classified into SC, LC, FC, and so on based on interface type. Fiber connector Fiber connectors are indispensable passive components in an optical fiber communication system. They allow the removable connection between optical channels, which makes the optical system debugging and maintenance more convenient and the transit dispatching of the system more flexible.
Page 56 • Never bend or curve a fiber when connecting it. After a fiber is installed well, the bend radius must be not less than 40 mm or 1.57 in (the minimum dynamic bend radius is 20 D, and the minimum static bend radius is 10 D. D indicates the outer diameter of dust caps). •...
Page 57 A mark "TO:" is located at the upper left corner of the label to identify the peer end of the cable on which the label is affixed. You can write the position of the peer device, control cabinet, distribution box, or power socket. The meaning of the dividing lines is the same as labels for network cables. Figure7-2 Label for power cords (1) Cable tie (2) Dividing line on the label...
Page 58 Figure7-3 Generic label (1) Dividing line on the label (2) Cut dotted line Labels for devices A device label is used to identify the device name, model, address, installation date, and so on. Filling in labels You can print or write desired contents on labels. HP recommends that you print labels. To print labels, select a label printer and a label template as needed.
Page 59 Figure7-4 Affixing a label Adhesive side B02 03 12 Figure7-5 shows the affixed labels when the cable is laid vertically and horizontally. Figure7-5 Affixed labels TO : B0 2 0 3 1 2 Affixing a label to a power cord Stick the label to the recessed rectangular area on the identification plate.
Page 60 Figure7-6 Affixing a label B03 -48V2 Bind cable ties on both ends of a cable. After the bundling, the finished identification plate must be on top of the cable in horizontal cabling, or on the right side of the cable in vertical cabling. Make sure the label is facing out, as shown in Figure7-7.
Page 61 Figure7-8 Affixing a generic label B02 03 12 Adhesive side Affixing a label to a device Remove the device label and stick it to the device. You can stick a device label to any desired position on the device. Guidelines •...
Page 62 Content Meaning Example Numbered in top-down and left-right order with two digits, for C—Slot number example, 01. Numbered in top-down and left-right order with two digits, for D—Ethernet port number example, 01. • M—Row number of the rack in the equipment room, in the range of A to Z.
Page 63 Table7-2 Information on labels affixed to the fiber between two devices Content Meaning Example • M—Row number of the rack in the equipment room, in the range of A to Z. • N—Column number of the rack in the MN—Rack number equipment room, in the range of 01 to For example, A01.
Page 64 Content Meaning Example B—Row number of the terminal device In the range of 01 to 99, for example, 01-01. C—Column number of the terminal device R—Optical receiving interface T—Optical transmitting interface Figure7-10 Example of a label on an optical fiber between two devices A 0 1 •...
Page 65 Content Meaning • n—Power port number in down-top and left-right order, in the range of 1 to 3. The label only carries location information about the peer equipment, control cabinet, or distribution box, while information about the local end is not necessary. Table7-4 lists information about two –...
Page 66 Content Meaning sockets. The label only carries location information about the peer equipment and the power socket, while information about the local end is not necessary. Make sure labels are affixed in the correct direction. After the cable ties are bundled onto the cable, the identification plates with the labels must face up, and the text on the labels in the same cabinet must be in the same direction, as shown in Figure7-13: Figure7-13 Example of labels on an AC power cord TO :...
Page 67 Figure8-1 Routing cables (M9000-X06) Routing power cords When you route power cords, take consideration of the layout of the equipment room, including the locations of the power distribution cabinet, AC power receptacles, and lightning protection box. Place all re-connecting facilities, such as receptacles, at the rack bottom (Do not place them at a location out of the rack and easy to reach.) The power supplies are located at the rear panel of the gateway.
Page 68 NOTE: The fiber's diameter refers to the outer diameter of the fiber jacket. Typically, the diameter of a single-core fiber is 0.9 mm (0.04 in), 2.0 mm (0.08 in), or 3.0 mm (0.12 in). Prerequisites Label cables before you route or bundle them. Cable management guidelines When you route and bundle up cables, follow these guidelines: •...
Page 69 Figure8-3 Cutting cable ties • When you bend cables, bind them as shown in Figure8-4. To avoid excessive stress causing cable core break, do not tie up the cables in the bending area. Figure8-4 Binding cables where they must be bent •...
Page 70 Figure8-5 Securely fastening cables (1) Flat washer (2) Spring washer (3) Nut • Fasten heavy or rigid power cords at the connectors to relief stress. • Do not use tapping screws to fasten the connecting terminals. • Bind together cables that are the same type and routed in the same direction. Table8-1 lists the cable bundling specifications.
Page 71 AC power cord—Remove the cable tie that secures the power cord, and then pull out the  plug. DC power cord—Remove the cable tie that secures the power cord, loosen the fastening  screw on the power cord, and then pull out the plug. Removing the console cable Pull the RJ-45 connector of the console cable out from the console port of the gateway.
Page 72 Remove the transceiver modules, if any, from the module. If no transceiver module is installed on the module, go to the next step. For how to remove a transceiver module, see "Replacing a transceiver module." Remove all modules from the chassis slots, and install filler panels to the empty slots. For how to remove a module and install a filler panel, see "Replacing a module."...
Page 73 To remove the chassis from the rack: Prepare the wooden carton and packing bag of the chassis. Make sure the carton and bag are clean, dry, and not damaged. Remove the top cap and side panels from the wooden carton. Use a Phillips screwdriver to loosen the screws that attach the mounting brackets to the rack.
Page 74 Figure9-3 Wooden pallet base Use screws to attach the L-type brackets to the chassis, as shown by callout 1 in Figure9-4. Move the chassis so that the mounting holes on the horizontal ear of the L-type brackets align with the mounting holes on the wooden pallet base. Use screws to attach the L-type brackets to the wooden pallet base, as shown by callout 2 in Figure9-4.
Page 75 Securing the chassis by using foam cushion Figure9-5 Repacking the gateway chassis (1) Bottom cap of the carton (2) Bottom foam cushion (3) Chassis (4) Front foam cushion (5) Top foam cushion (6) Accessory box (7) Paper corner protector (8) Carton (11) Top cap of the carton (12) Wooden pallet base To repack the gateway chassis:...
Page 76 Remove the chassis from the rack and put the removed chassis into the anti-static shielding bag. Then, place the chassis into the notches in the bottom foam cushion, as shown by callout 3 in Figure9-5. Take out the front foam cushion and insert it into the notch in front of the chassis front on the bottom foam cushion, as shown by callout 4 in Figure9-5.
