Right
① USB Port (Master)
Designs can be uploaded to or downloaded from the USB memory through the ports.
② USB Port (Slave)
Designs can be uploaded to or downloaded from the USB memory through the ports.
(This is under development.)
③ Connecting floppy drive to the cable
The portable floppy disk drive can be connected to the cable.
④ Serial Port
Serial port can be used for serial communication.
▶Back
The connector cover is designed to prevent dusts and other foreign materials from gathering. When linking to
the connector, press the cover to open it.
① Keyboard Port
② VGA (Monitor) Port
③ Serial Port
④ LAN Port for networking
⑤ Cable connection for power signal transmission
① ② ③
[Fig1.1-3]
1 1 - - 2 2
① ② ③ ④
[Fig1.1-2]
[Fig1.1-4]
