SWF Dual Function E Series User Manual page 67

① Max Speed
⑭ Optimize Method
It sets the maximum embroidery speed
Gauge refers to making running stitches in parts off the design exclude by certain length. It sets the distance from
- Basic setting is 1000rpm and you can set it in the range of minimum to 1200rpm in the unit of 1rpm.
the exclude to the gauge.
- Basic setting is 10mm and you can set it in the range of 1~30mm.
② Min Speed
It sets the minimum embroidery speed.
- Basic setting is 300rpm and you can set it in the range of 300 to maximum rpm in the unit of 1rpm.
⑮ S/W Limit Setting
③ EMB Speed
It sets whether to use the virtual frame limit function.
- Basic setting is NO.
It sets the embroidery speed.
- Basic setting is 800rpm and you can set it in the range of minimum and maximum rpm (set in the machine
parameter) in the unit of 1rpm.
⒃ Thread Break Moving
④ Inching Speed
The frame automatically moves to the back of the machine when the machine stops after detecting a thread break
It sets the speed of the low-speed stitching at the start of the embroidery.
for convenient threading of the upper thread. You can set the length of the frame movement.
- Basic setting is 180rpm and you can set it in the range of 50~200rpm in the unit of 1rpm.
- Basic setting is 0mm and you can set it in the range of 0~50mm in the unit of 1mm.
⑤ Jump Speed
It sets the limit of the jump stitching (the frame moves without stitching).
⒔ Lock Stitch
- Basic setting is 750rpm and you can set it in the range of minimum to maximum speed in the unit of 1rpm.
It repeats back-tack in order to prevent unraveling of thread during trimming.
- Basic setting is 1 stitch and you can set it in the range of 1-5 stitches in the unit of 1, 3, or 5 stitches.
⑥ Slow Speed
It sets the embroidery speed during slow speed.
- Basic setting is 650rpm and You can set it in the range of minimum and maximum speed in the unit of 1rpm.
⑦ After Trimming Inching Stitch
It sets the number of low-speed stitching (inching) when the machine meets a color change signal during
embroidery or when the embroidery is completed for certain design.
- Basic setting is 3 stitches and you can set it in the range of 2-10 stitches in the unit of 1 stitch.
⑧ Auto Trimming
It sets whether or not to use the automatic trimming function.
- Basic setting is YES. Select NO to turn this function off.
⑨ Auto Color Change
It sets whether or not to use the automatic color change function.
- Basic setting is YES. Select NO to turn this function off.
5 5 - - 3 3 5 5
