Machine Setting and Troubleshooting (
7.3.0

7.3.1 Rear Side of Control Box

<Fig. 7.3.1-1> is the rear side of Control Box.
① MC1(L)
Main Driver
② MC1(L)
XY Driver
③ MC2(R)
XY Driver
④ MC2(R)
Main Driver
① MC1 Main Driver
② MC1 XY Driver
③ MC2 XY Driver
④ MC2 Main Driver
⑤ IO Ass'y
⑥ LAMP Ass'y
In case of Dual Function 2× × 2 or above)
※ ※
7 7 - - 1 1 1 1
⑤ IO Ass'y
⑥ LAMP Ass'y
[Fig.7.3.1-1]
