⒕ Speed Switching Data
When the fabric is too heavy, disturbing normal machine operation, it slows down the overall embroidery speed.
- The default value is "high speed(1)". Whenever entering "low speed(0)", the embroidery speed is reduced by
30~50rpm.
⒖ Thread Break Sensor
The machine will stop if it senses the repeated break of the upper thread in the number set in this function. This is
to prevent false detection due to sensor malfunction.
- Basic setting is 3 stitches and you can set it in the range of 0~10 stitches. If you select "0", the thread break
function will be turned off.
⒗ Thread Break Method
It sets the sensitivity of the thread detection.
- Basic setting is LOW (0) and you can set it at HIGH (2) or MEDIUM (1).
(21) Thread Length Trimmed
It sets up the remaining length of the upper thread in the needle after automatic trimming.
- The default value is "Midium(1)". To make it shorter, choose "Short(1)". To make it longer, choose "Long(2)".
(22) Frame Start Angle For 'A' Area
It sets the rotation angle of the main axis when the frame starts to move - if the width of the embroidery is shorter
than 1.9mm.
- Basic setting is 240° and you can set it in the range of 230-250° in the unit of 1°.
(23) Frame Start Angle For 'B' Area
It sets the rotation angle of the main axis when the frame starts to move - if the width of the embroidery is longer
than 2.0mm.
- Basic setting is 240° and you can set it in the range of 230-250° in the unit of 1°.
[Note]
Selection of polyester yarn mode：If the frame feed starting angles (A) and (B) are set at 250。 , the polyester
yarn mode will be selected and the looping, which occurs during embroidery, can be prevented.
(24) Picker Off Time (Trimming)
When automatic trimming is performed, it sets the remaining length of the upper thread in the needle.
- The default is 13[ang]. If the set value is lower than the default, the length of the upper thread will get shorter.
If vice versa, the length of the upper thread after trimming will get longer. The value can be set within the range
of 0~60[ang] and adjusted by the unit of 1[ang].
