7

Troubleshooting

Error displays and troubleshooting

7.1.0

7.1.1 Main shaft motor and others

No. ERROR TYPE
100 Wrong position of main shaft stop
101 Error in main shaft motor driver
102 Main shaft overload
103 Trimmer sensor return failure
104 Error in start switch
105 Error in stop switch
107 Valve failure
108 Air pressure error
110 AC Line error

7.1.2 X,Y motors

No. ERROR TYPE
200 +X limit detection failure
201 -X limit detection failure
202 +Y limit detection failure
203 -Y limit detection failure
204 Error in X-axis driver
205 Error in Y-axis driver
206 Wiper return failure
207 Error in trimmer return
ERROR
Main shaft didn't stop at 100°
Error in main shaft motor driver
Thread tangle around hook,
Needle controller malfunction,
Thread tangle when trimming
Trimming sensor does not return
after trimming
START is pressed when the
power is turned on
STOP is pressed when the power
is turned on
Error occurs when valve opens
Error occurs when air pressure is
below the threshold(Sequin)
This error occurs when the joint
board has problems
ERROR
Frame reached ＋X limit.
Frame reached －X limit.
Frame reached ＋Y limit.
Frame reached －Y limit.
Error in X-axis driver
Error in Y-axis driver
Wiper motor does not return
Trimmer solenoid does not return
7 7 - - 1 1
CORRECTION
Use a lever to adjust the shaft
angle at 100°
Turn the main switch OFF and ON again.
Check the hooks on all heads and
turn the main switch OFF and ON
again.
Check the trimming unit.
Check if START touches the
connector
Check if STOP touches the
connector
Replace the joint board
CORRECTION
Move the frame in the －X
direction.
Move the frame in the ＋X
direction.
Move the frame in the －Y
direction.
Move the frame in the ＋Y
direction.
Turn main switch OFF and ON
again
Turn main switch OFF and ON
again
Repair wiper mechanism
Repair trimmer mechanism
