⑨ Jump convert
moves the frame after trimming when you want repetition jumps in the number above the set value.
For instance, if the set jump value is 5 and you come across a repetition jump code during embroidery, up to 4
stitches will not be trimmed (jumped). But when you come across a repetition jump code of over 5 stitches, the
machine will trim first, then jump 5 stitches, and resume embroidery. Basic setting is 3 stitches and you can set in
the range of 0-10 stitches in the unit of 1 stitch.
[CAUTION]
If you set this function at "0", the machine will jump without trimming when you meet repetition jump codes
regardless of the number of repetition jump stitches.
In case the length of the stitches is 4
( Thread connects to next design )
In case the length of the stitches is 5
( More to next design after thread trim )
5 5 - - 2 2 9 9
[Fig.5.9.1-6] Setting trimming by Jump at 5 stitchs
