7.1.3 Needle(color) change

No. ERROR TYPE
300 Needle position error

7.1.4 Encoder

No. ERROR TYPE
400 Error in A of main shaft encoder
401 Error in Z of main shaft encoder

7.1.5 Repeat

No. ERROR TYPE
501 Error in repeat setting
ERROR
Needle does not come to the
correct position when changed
ERROR
Error in A signal of the main
shaft encoder.
Error in Z signal of the main
shaft encoder.
ERROR
Off the repeat setting limit
(X repeat×Y repeat >99)
7 7 - - 2 2
CORRECTION
Manually turn the needle bar,
check the load, and locate it in the
right position.
CORRECTION
Check cable connection. Turn the
main power OFF and ON again.
Check cable connection. Turn the
main power OFF and ON again.
CORRECTION
Adjust the repeat setting so that
X repeat×Y repeat <99
