SWF Dual Function E Series User Manual page 59

⑤ X Satin
sets the scope of the satin if the design has satin stitches.
You can set the satin scope in the X direction by increasing the default value in the unit of 0.1mm.
⑥ Y Satin
sets the satin scope in the Y direction.
⑦ Start Stitch
sets the starting stitch of the design. You can set the number of stitches to be skipped before the first stitch.
For instance, a design with total 10000 stitches (see below) can be made with the left side having the entire
stitches and the right having only 5000 stitches started at the 5000th stitch.
Start Point
[Fig.5.9.1-2]
Start Point
Basic shape
(Number of entire stitch-10000)
5 5 - - 2 2 7 7
End Point
Set-up number of
stitch to 5000
[Fig.5.9.1-3]
Part that skip over
embroidery among the
entire design
(5000 stitches)
End Point
[Fig.5.9.1-4]
