3.1 Technical Specification

Programmable
Outputs
PGM 1
Speaker
Strobe Output
Bell Output
XPGM 1 (Input 7)
XPGM 2 (Input 8)
ATE Outputs
All outputs are programmed in "CHANGE OUTPUTS" in the Engineer menu.
Input Resistance
Normal
Burglary Alarm
Fault
Masking (6k8)
Tamper
All inputs are programmed in "PROGRAM INPUTS" in the Engineer menu.
Fuses
Bell Fuse for bell terminals
Aux Fuse for aux terminals
RS485 Bus Fuse for bus terminals
Battery Fuse for battery terminals
230V Mains Fuse for mains terminals
Panel Power Supply Output
Output Voltage
Output Current EURO 46S
Output Current EURO 46L
Power Supply Type A.
Maximum output peak voltage: Max 100 mV
SD Voltage which the deep discharge protection function will operate at: 10.5V
Over Voltage Protection Trigger Voltage: 18V
NOTE 1. EURO power supplies are NOT designed for use with multiple batteries connected.
NOTE 2. System load should not exceed the panel power supply output shown above or the maximum load
supportable by the battery for the specified backup time, as in the table shown below.
NOTE 3. The power ratings are based on battery shown in table – but ANY battery capable of supporting the
system load for the required time may be used without affecting these ratings.
Panel Power Supply Input
Mains Supply Voltage AC
Transformer Rating EURO 46S
Transformer Rating EURO 46L
Battery Charging Specification
Float Voltage
Battery low voltage cut off
Recharge time
EURO 46 Installation Manual
Power Rating
Relay, 3A, max 30V
16 ohms
500mA
500mA
50mA
50mA
2mA
1k / 1k DEOL Range
0k5 to 1k4
1k5 to 5k9
6k to 8k1
8k2 to 17k
<0k5 or <17k
Value
F800mA quick blow 250V
F800mA quick blow 250V
F800mA quick blow 250V
T1.6A slow blow 250V
T500mA H anti-surge slow blow 250V
Nominal
13.7V DC
1A Continuous
1.5A Continuous
Nominal
230V AC at 50Hz
18VA
45VA
13.8v DC
10.5v
<24 Hours
Normal State
Changeover NC & NO
No tones
12v
12v
Floating
Floating
5v
4k7 / 2k2 DEOL Range
1k4 to 2k9
4k2 to 7k8
8k to 11k3
11k6 to 22k
<1k4 or >22k
Range
10-15V DC
1.5A peak, during battery charging
2.0A peak, during battery charging
Control Panel Type
Standby battery capacity
current
Standby battery capacity
current
Page: 9
Active State
Changeover NC & NO
Repeat RKP tones & internal sounder
0v
0v
0v
0v
0v
4k7 / 4k7 DEOL Range
3k7 to 8k3
8k4 to 10k2
10k3 to 14k9
15k to 22k
<3k7 or >23k
Type
Glass
Glass
Glass
Glass
Ceramic
Range
-15% +10%
18V at 1.0A
18.5V at 2.5A
300mA (3A to 7A)
700mA (8A to 17A)
