7.7 Connecting The Enforcer Wireless Zone Expander Module (EURO-ZEM32-WE)

EURO-ZEM32-WE
The EURO-ZEM32-WE is a wireless input
expander that supports Two Way
wireless Enforcer technology. Each
expander will allow 32 wireless inputs.
The first expander on the bus will allow
32 wireless keyfobs and 2 wireless bells.
The EURO 46 will support 1 x EURO-
ZEM32-WE. (A maximum of 32 wireless
inputs).
Please see page: 4.
7.7.1 EURO-RIX32-WE Technical Specification
EURO-RIX32-WE (Two Way Wireless Input Expander)
Input Voltage
Current Consumption
Radio Frequency
Dimensions (metal box)
Colour and Casing
Indication
Temperature
Humidity
Weight
7.7.2 Addressing the EURO-ZEM32-WE (From the Expander)
The EURO 46 will support both wired and wireless expanders on the same bus.
Wireless sounders and Keyfobs must be learned to Address 0.
NOTE: Please make sure that you address the EURO-ZEM32-WE while the tamper switch is open. The
address will then be assigned when the tamper is closed.
EURO 46 Installation Manual
9-14V
60mA quiescent
115mA during transmission
868MHz FM Transceiver Narrow Band. Range: 300m open space
173 x 125 x 32mm
White plastic casing
LEDs (Power and Data)
Operational: -10°C to +50°C
Certified: -10°C to +40°C
Storage: -40°C to +80°C
85% @ 25°C
0.24kg
