1.3 EURO Input Mapping Overview:

1.3.1 EURO 46 Input Mapping Table:
DEVICES
EURO 46 PCB
EURO-ZEM8 / EURO-ZEM8+/ EURO-ZEM8+PSU / EURO-ZEM32-WE
EURO-LCD
EURO-LCD / EURO-PROXI*
Total
NOTE 1: 1 x EURO-ZEM32-WE can be connected to the EURO 46. This Zone Expander Module
allows 32 inputs that are separated into 4 addresses (each address enables 8 wireless inputs). It is
possible to mix the wired and wireless remote expanders.
When installing a EURO-ZEM32-WE, the first wireless expander (Address 0) will learn the 32
wireless keyfobs and 2 wireless sounders. If this expander is disconnected, the keyfobs and
sounders will need to be learnt on another expander again.
*NOTE 2: If the EURO-PROXI (Internal Tag Reader) is programmed as a 'Set/Unset' device, 2
inputs are enabled. If the EURO-PROXI is programmed as 'Entry Control' or 'Access Control' only 1
input is enabled.

1.4 Output Mapping Overview

1.4.1 EURO 46 Output Mapping Table
DEVICES
EURO 46 PCB
ATE Outputs (using communication loom)
EURO-OEM8R8T / EURO-OEM16R+PSU
EURO-ZEM8 / EURO-ZEM8+/ EURO-ZEM8+PSU
EURO-LCD
EURO-LCD / EURO-PROXI / EURO-PROXE
Total
EURO 46 Installation Manual
Page: 6
Address Input Numbers
PCB 1-8
0 9-16
1 17-24
2 25-32
3 33-40
0 41-42
1 43-44
2 45-46
46
Address Output Numbers
PCB 5 (2 shared)
Loom 10
0 1-16
1 17-32
0 1-4
1 1-4
2 1-4
3 1-4
0 1
1 1
2 1
3 1
4 1
5 1
69
