8.9 Problem Solving

One of the most frequent problems in not being able to assign the detectors to the Radio Expander is
that the jumper on the detector PCB has not been put in place on the 'EU' pins. This makes sure the
transmitter transmits at the correct 868MHz frequency which the input expander uses.
Make sure that the 'serial' jumper on the radio expander is in the 'MF' position.
If there is "33" displayed on the screen and can't be cleared, it is because the expander has been
selected for "A0" not "E0". You will need to power down the expander and address it again.

8.10 Technical Specification

Radio:
Housing Material:
Closure:
Dimensions:
Weight:
Power Requirements:
Battery Capacity:
Back-up Battery Life:
Operating Environment:
Batt. Charger Operating
Environment:
Conformity:
EURO 46 Installation Manual
THE RADIO EXPANDER
Inovonics Wireless EchoStream using Pan-European 868MHz
ABS
Latching with optional screws for high security installs
162.0 x 91.4 x 27.9 mm
204 grammes
12-24V AC or DC
1800mAH at 3.7V
24 hours typical
0° - 60° C up to 90% relative humidity (non-condensing)
0° - 40° C
Meets or exceeds EN50131-5-3 at grade 2
