1.3 EURO Input Mapping Overview:

1.3.1 EURO 162 Input Mapping Table:
DEVICES
EURO 162 PCB
EURO-ZEM8 / EURO-ZEM8+ / EURO-ZEM8+PSU / EURO-ZEM32-WE
EURO-ZEM8 / EURO-ZEM8+/ EURO-ZEM8+PSU
EURO-LCD
EURO-LCD / EURO-PROXI*
Total
NOTE 1: 3 x EURO-ZEM32-WE can be connected to the EURO 162. This expander allows 32 inputs
which are separated into 4 addresses (each address enables 8 wireless inputs). It is possible to mix
the wired and wireless remote expanders.
When installing a EURO-ZEM32-WE, the first wireless expander (Address 0) will learn the 32
wireless keyfobs and 2 wireless sounders. If this expander is disconnected, the keyfobs and
sounders will need to be learnt on another expander again.
*NOTE 2: If the EURO-PROXI (Internal Tag Reader) is programmed as an 'Set/Unset' device, 2
inputs are can be programmed. If the EURO-PROXI is programmed as 'Entry Control' or 'Access
Control' only 1 input can be programmed.
EURO 162/280 Installation Manual
Page: 7
Address Input Numbers
PCB 1-8
0 9-16
1 17-24
2 25-32
3 33-40
4 41-48
5 49-56
6 57-64
7 65-72
8 73-80
9 81-88
10 89-96
11 97-104
12 105-112
13 113-120
14 121-128
15 129-136
16 137-144
17 145-152
0 153-154
1 155-156
2 157-158
3 159-160
4 161-162
162
