Privacy Wall (without 1" flange - continued)
4. Peel the backing film from the adhesive mounting strips
on the back of the glass mounting bracket. Ensuring the
glass mounting bracket is level and against the frame,
press the glass mounting bracket onto glass. Hold even
pressure for at least 15 seconds.
5. Plug the PoE cable into the back of the RoomWizard.
6. Attach the RoomWizard to the glass mount bracket.
7. Peel or cut the tabs on protective cover, then slide to
remove the protective cover.
5
6
RoomWizard Mounting Kits
©
Installation Instructions
REMOVE BACKING FILM
FROM ADHESIVE STRIPS
4
7
Peel or cut the tabs on the protective cover.
