Hard Surfaces (continued)
4. Route the PoE cable through the mount bracket.
5. Replace the mount bracket onto the wall and install the
four (4) screws and four(4) washers using a #2 Phillips
screwdriver. Ensure the wall mount bracket is level before
final tightening.
6. Plug the PoE cable into the back of the RoomWizard.
7. Attach the RoomWizard into the mount bracket.
8. Peel or cut the large tabs on protective cover, then slide to
remove the protective cover.
5
Washer and
Screw
6
7
RoomWizard
©
Installation Instructions
4
8
Peel or cut the tabs on the protective cover.
