PoE Cable Drops

• PoE Cable drops should be located 52" (1325cm) from the
floor.
• If running PoE cable without connector, minimum hole size
½"
should be Ø (12mm).
• If running PoE cable with connector, the minimum hole size
should be Ø 5/8" (16mm).
• Please follow the exposed PoE cable length as defined on
Table 1.
• Allowing for PoE cable to move in and out of structure is
always recommended whenever possible.
See Table 1
RoomWizard
Installation Instructions
½
" (12mm) or 5/8" (16mm)
DRILL BIT FOR PoE CABLE
PoE CABLE
Mounting Kits
©
52"
(134cm)
to floor
