Installation

4 Installation

4.1 Mechanical Installation

Select the best possible operation site by considering:
•
Ambient operating temperature.
•
Installation method.
•
Cooling.
•
Position of the frequency converter.
•
Cable routing.
•
Power source supplying correct voltage and
necessary current.
•
Motor current rating within the maximum current
from the frequency converter.
•
Correct rating of external fuses and circuit
breakers.
Cooling and Mounting:
•
Top and bottom clearance for air cooling must be
provided, see Table 4.1 for clearance requirements
•
Consider derating for temperatures starting from
45 °C and elevation 1000 m above sea level. See
Design Guide for details on derating.
Enclosure
Clearance above and below the
unit [mm]
Table 4.1 Minimum Airflow Clearance Requirements
•
Mount the unit vertically
•
IP20 units allow side-by-side installation
•
Improper mounting can result in overheating and
reduced performance
•
Use the slotted mounting holes on the unit for
wall mounting, when provided
•
See chapter 8.4 Connection Tightening Torques for
proper tightening specifications.
MG06A502
Quick Guide
J1-J5 J6/J7
100 200
