Danfoss VLT AutomationDrive FC 360 Quick Manual page 8

Introduction
1 1
1 J7 frequency converter
2 Removable fan assembly
3 M5 screw X4 (for fan assembly)
4 NLCP (accessory)
5 Option B (MCB 102/103 accessories)
6 I/O terminals
7 I/O terminals
8 Pluggable RS-485 terminals
9 Relay terminal 1&2, fixed
Illustration 1.3 Exploded View, J7 (55 kW, 75 kW), IP20
6
Quick Guide
3
2
1
18
16
15
17
10
11
12
13
14
15
16
17
18
Danfoss A/S © Rev. 06/2014 All rights reserved.
4
5
6
7
8
9
10
11
12
13
14
I/O cable clamps
Terminal cover
Motor terminals
Load sharing terminals
Removable plugger (for load sharing terminal)
Shielded cable grounding clamps
Mains terminals
Decoupling plate (accessory)
M4 screw X3 (for decoupling plate)
MG06A502
