Specifications
Digital outputs
Programmable digital/pulse outputs
Terminal number
Voltage level at digital/frequency output
Maximum output current (sink or source)
Maximum load at frequency output
Maximum capacitive load at frequency output
Minimum output frequency at frequency output
Maximum output frequency at frequency output
Accuracy of frequency output
Resolution of frequency output
1) Terminal 27 and 29 can also be programmed as input.
The digital output is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
Control card, 24 V DC output
Terminal number
Maximum load
The 24 V DC supply is galvanically isolated from the supply voltage (PELV), but has the same potential as the analog and digital
inputs and outputs.
Relay outputs
Programmable relay outputs
Relay 01 and 02
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Minimum terminal load on 01–03 (NC), 01–02 (NO)
1) IEC 60947 t 4 and 5
The relay contacts are galvanically isolated from the rest of the circuit by reinforced isolation.
Control card, +10 V DC output
Terminal number
Output voltage
Maximum load
The 10 V DC supply is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
Control characteristics
Resolution of output frequency at 0–500 Hz
System response time (terminals 18, 19, 27, 29, 32, 33)
Speed control range (open loop)
Speed accuracy (open loop)
Speed accuracy (close loop)
All control characteristics are based on a 4-pole asynchronous motor.
MG06A502
Quick Guide
1)
on 01–02/04–05 (NO) (Resistive load)
on 01–02/04–05 (NO) (Inductive load @ cosφ 0.4)
1)
1)
on 01–02/04–05 (NO) (Resistive load)
1)
on 01–02/04–05 (NO) (Inductive load)
1)
on 01–03/04–06 (NC) (Resistive load)
on 01–03/04–06 (NC) (Inductive load @ cosφ 0.4)
1)
1)
on 01–03/04–06 (NC) (Resistive load)
Danfoss A/S © Rev. 06/2014 All rights reserved.
Maximum error: 0.1 % of full scale
01–03 (NC), 01–02 (NO), 04–06 (NC), 04–05 (NO)
24 V DC 10 mA, 24 V AC 20 mA
1:100 of synchronous speed
± 0.5% of nominal speed
± 0.1% of nominal speed
2
1)
27, 29
0–24 V
40 mA
1 kΩ
10 nF
4 Hz
32 kHz
10 bit
12
100 mA
8 8
2
250 V AC, 3 A
250 V AC, 0.2 A
30 V DC, 2 A
24 V DC, 0.1 A
250 V AC, 3 A
250 V AC, 0.2 A
30 V DC, 2 A
50
10.5 V ±0.5 V
15 mA
± 0.003 Hz
≤ 2 ms
