Introduction

1.6.2 Exploded Views

3
4
1 NLCP (accessory)
2 Control cassette
3 RFI switch (screw M3x12 only)
4 Removable fan assembly
5 Grounding clamp (accessory)
6 Shielded cable grounding clamp and strain relief (accessory)
7 Motor terminal (U V W) and brake and load sharing terminals
8 PE ground
9 3-Pole relay 1
Illustration 1.2 Exploded View, J1-J5 (0.37–22 kW), IP20
MG06A502
Quick Guide
1
2
8
7
6
5
10
11
12
13
14
15
16
17
Danfoss A/S © Rev. 06/2014 All rights reserved.
17
16
15
14
13
12
11
10
9
2-Pole Relay 2 (0.37–7.5 kW), pluggable
3-Pole Relay 2 (11–22 kW), pluggable
Mains terminals
Cable strain relief (0.37–2.2 kW: accessory)
Pluggable RS-485 terminal
Fixed I/O terminals
Fixed I/O terminals
Terminal cover
Option-B (MCB102/103 accessories)
