Application Examples
FC
+24 V 12
D IN 18
D IN 19
COM 20
D IN 27
D IN 29
D IN 32
D IN 33
D IN
31
+10 V 50
A IN
53
A IN
54
COM
55
A OUT
42
45
A OUT
Table 6.8 Speed Up/Down
S p e e d
R e f e r e n c e
S t a r t ( 1 8 )
F r e e z e r e f ( 2 7 )
S p e e d u p ( 2 9 )
S p e e d d o w n ( 3 2 )
Illustration 6.1 Speed Up/Down
CAUTION
Thermistors must use reinforced or double insulation to
meet PELV insulation requirements.
MG06A502
Quick Guide
Parameters
Function Setting
5-10 Terminal 18
[8] Start*
Digital Input
5-12 Terminal 27 [19] Freeze
Digital Input Reference
5-13 Terminal 29 [21] Speed
Digital Input Up
5-14 Terminal 32 [22] Speed
Digital Input Down
* = Default value
Notes/comments:
Danfoss A/S © Rev. 06/2014 All rights reserved.
FC
1-90 Motor
+24 V 12
Thermal
D IN 18
Protection
D IN 19
1-93 Thermistor
COM 20
Source
D IN 27
6-19 Terminal 53
D IN 29
mode
D IN 32
D IN 33
D IN
31
* = Default value
Notes/comments:
+10 V 50
A IN
53
If only a warning is desired,
A IN
54
1-90 Motor Thermal Protection
COM
55
should be set to [1] Thermistor
A OUT
42
warning.
A OUT 45
Table 6.9 Motor Thermistor
Parameters
Function Setting
[2]
Thermistor
trip
[1] Analog
input 53
[1] Voltage
39
