OUTPUT AND ACCESSORIES
Output Value - Accessories
0 1
24 V
-
+
24 V
1 13
0 14
24 V / 25 W
24 V / 25 W max.
0 14
0 15 24 V / 1,2 A
0 15
12V~ / 15 W
AUX
COM
BAT
2 x 12 V / 2 Ah
Power supply output for external accessories, including automation
status lamp. Electronically protected output.
/ 0,5 A
Automation status lamp (proportional).
The light switches off when the automation is closed; the light switches
/ 3 W
frequency while the automation is operating.
Flashing light (LAMPH). Selecting
light activates simultaneously with the opening and closing opera-
LAMPH
tion.
NOTE: with automatic closing enabled, there is a pre ashing of 3 s
that cannot be regulated.
Courtesy light. Selecting
nect a courtesy light that activates each time a total or partial ope-
ning command or closing command is received.
The duration of the light can be regulated via the adjustment
and
Electric block 24V.
Electric lock 12 V.
series.
radio receivers, magnetic spirals, etc. The action of the card can be
selected via the selection
WARNING: the plug-in cards must be inserted and removed with
the power supply disconnected.
The storage module allows remote controls to be stored and the type
on page 4).
Storage
If the control panel is replaced, the storage module being used can
module
be inserted in the new control panel.
WARNING: the storage module must be inserted and removed with
the power supply disconnected.
Battery operating.
supply is on. If the power supply is off, the control panel is powered
by the batteries until power is re-established or until the battery
voltage drops below the safety threshold. If this occurs, the control
BATK1
panel turns off.
WARNING: the batteries must always be connected to the control
panel for charging. eriodically check the ef ciency of the batteries.
NOTE: the operating temperature of the rechargeable batteries is
approximately +5°C/+40°C.
Description
.
8
