SOFA1-SOFA2 or GOPAVRS self-controlled safety edge

5.1
Command
SAFETY TEST
SOFA1-SOFA2
GOPAVRS
1 0 41
1 6 N.C. OPENING SAFETY
DEVICE
1 8 N.C. REVERSAL
SAFETY
CONTACT
Function
Insert the electronic card SOFA1-SOFA2 or GOPAVRS in the
housing AUX on the control panel.
Selecting
edge test before each operation. If the test fails, an alarm message
is visualised on the display.
Selecting
SOFA1-SOFA2 to terminals 1-6 on the control panel (in series with
the photocell output contact, if installed).
Selecting
SOFA1-SOFA2 to terminals 1-8 on the control panel (in series
with the photocell output contact, if installed).
Description
, the terminal 41 activates a safety
, connect the output contact of device
, connect the output contact of device
