Ec Declaration Of Conformity - DITEC Entrematic HomeLink E2H Installation Manual

2.

EC DECLARATION OF CONFORMITY

Manufacturer: DITEC S.p.A.
declares that the control panel E2H is in conformity with the provisions of the following EC directives:
EMC Directive 2004/108/EC;
Low Voltage Directive 2006/95/EC
R&TTE Directive 1999/5/EC
Caronno Pertusella, 2010-09-09
3. TECHNICAL DATA
Memory module
Power supply
F1 fuse
Motor output
Accessories power supply 24 V
Temperature
Degree of protection
Memorizable
radio codes
Radio frequency
i
NOTE: the given operating and performance features can only be guaranteed with the use of DITEC
accessories and safety devices.
3.1 Applications
ARCBH
OBBI3BH
OBBI3BFCH
LUXO3BH
LUXO4BH
3M1OB
3M1AR
3M1LX
230 V~ 50/60 Hz
F1,6A
24 V 2x4,5 A max
0,5 A
min -20 °C max 55 °C
IP55
100
200 [BIXMR2]
433,92 MHz
FACIL3H
FACIL3EH
3M1FC
F1,6A
24 V 2x6 A max
24 V 0,5 A
min -20 °C max 55 °C
IP54
100
200 [BIXMR2]
433,92 MHz
4
