Form an eye in one end on the ends of the
welding rod as shown.
Join both welding rods together in a connector block ( lightly tighten)
Hook the eye at the end of rod through the 2mm dia hole in the axle holder.
Tighten the loop afterwards with a pair of pliers so that it cannot spring out.
The tracking can be adjusted later when both sets of wheels are in position.
Part Nr:50
Cut off 8 blocks from the connector block and
fix with 2 self tapping screws (46)
centrally between the two rear axle holders.
90
Hook the eye in the welding rod
through the hole and tighten
Part Nr. 46
