Fork lift truck
Hide thumbs

Advertisement

Assembling the fork
Nuts M4
(Part Nr: 34)
Domed nut
(Part Nr:35)
Nuts M4
(Part Nr: 34)
Machine screw
M4 x 8
(Part Nr 33)
Machine screw
M4 x 8
(Part Nr 33)
Front view
Fork lift truck "MANITOU"
9
101.200
View from behind
