Opitec Hobbyfix Flip Manual

M e c h a n i c a l G r a s s h o p p e r
Necesary tools:
Fretsaw
Drilling machine
Drills ø2, ø 5mm
Countersink
Sandpaper -File
Wood glue
Screwdriver (Crosshead/slot)
Pencil
Ruler
PARTS LIST
Wooden block
Wooden strip
Wooden wheels
Dowel
Screws
Screws
Pipe cleaner
Screw eyelet
D111644#2
111.644
" F l i p "
The OPITEC range of projects is not intended as play
young people learning the skills of Craft, Design and
Technolo- gy.These projects should only be underta-
ken and tested with the guidance of a fully qualified
adult. The finished projects are not suitable to give to
children under 3 years old. Some parts can be swallo-
Quantity Size in mm
1
2
4
1
6
2
1
1
Please Note
toys for young children.They are teaching aids for
wed. Dan- ger of suffocation!
Description
200x40x20 Body
200x10x10 Legs
40x10 Wheels
100x4 Axles
3x20 Leg fixings
2,9x9,5 Feeler fixing
50x8 Feelers
16 Tether
Part Nr.
1
2
3
4
5
6
7
8
1
