Part Nr: 20 22
Mount the completed fork assembly. Turn the worm by hand
so that the fork assembly lowers by about a centimetre
Finally add a domed nut to the tops of the guide and drive (
Parts Nr: 35 and 35)
Part Nr. 35
Part Nr. 32
Fork lift truck "MANITOU"
13
101.200
