Part Nr:42
Once you have cut out the pattern Nr. 6 drill the 4mm holes
Fold the edges as shown using vice or folding bars.
The small short folds can be folded with pliers
View from underneath
Part Nr:43
Cut out the pattern 5 from the metal sheet. Bend using a vice (Use soft jaws) at an
angle of 80 degrees
Finally add the foam squab and back ( Part Nr :38 ) use contact glue
35
30
Shape to suit with a file or sandpaper
