Parts list
It is recommended that you sort through and identify the various parts before starting this project.
Please remove any 'burr' from the metal parts with a file or emery cloth before assembly!
Quantity Description
1 Chassis/base
2 Rear axle bearing
2 Steering rods
2 Wheels (large)
3 Wheels (small)
2 Motor R 20
2 Motor drive gear
2 Angle plates
4 Distance rollers
4 Machine screws
4 Nuts
4 Metal axles
4 Double gears 50/10
4 Double gears
4 Tube spacers
2 Distance washers
2 Reducers 4/3mm
2 Fork guides
1 Hub rod
2 Fork holder
1 Fork coupling
2 Forks
1 Fork drive
1 Motor R20
1 Motor fixing
1 Drive worm gear
2 Brass tubes
14 Machine screws
2 Machine screws
6 Washers
27 Nuts
3 Domed nuts
6 Machine screw
24 Nuts
10 Domed nut
1 Steering joiner
2 Battery and seat fixing
1 Seat squab
1 Motor cover
2 Side panels
1 Wheel cover
1 Roof
1 Seat
4 Roof support
2 Flat connectors
4 Self tappers
1 Hand control housing
1 Press switch
2 Slide switches
2 Cable joiner
1 Flat cable
1 Round cable
PartNo Material
1 Holed metal
2 Holed metal strip
3 Welding rod
4 Plastic
5 Plastic
6 Metal
7 Plastic
8 Plastic
9 Plastic
10 Steel
11 Steel
12 Steel
13 Plastic Red/brown (tight)
14 Plastic White grey (loose)
15 Brass
16 Plastic red or white
17 Plastic
18 Threaded steel rod
19 Threaded steel rod
20 Steel holed strip
21 Steel holed strip
22 Steel holed strip
23 Plastic double gear 30/10 Red/brown
24 Metal
25 Steel
26 Plastic
27 Tube 5mm dia x 250
28 Steel
29 Steel
30 Steel
31 Steel
32 Steel
33 Steel
34 Steel
35 Steel
36 Connecting block, cut off
37 Sticky pads
38 Hard foam or similar
39 Cut from sheet metal
40 0,29 x 200 x200
41 Cut from sheet metal
42 0,29x300x150mm
43
44 Steel/Threaded rod
45 Metal
46 Steel
47 Polystyrol
48 Connector
49 2 xUM
50 Connecting block (to be cut)
51a
51b
Fork lift truck "MANITOU"
1
130 x 166mm
15 x 60 ( 4 holes)
1mm x 100mm
3mm x 70mm
M4 x 150mm
M4 x 150mm
5x15 x 105mm (7 holes)
1x45 (3holes)
1x15x250mm
200x155mm
170x132mm
M4 x 100mm
3 x80x130mm
101.200
Size
55mm dia
43mm dia
21mm dia
25mm dia
M3 x 35mm
M3
M3x 8mm
M3 x 25mm
M3
M3
M3
M4 x 8mm
M4
M4
70 x 45mm
100x70mm
70x40mm
6,3mm
2,9x9,mm
