Table Of Contents - Videx IP videokit IPVK/6296 Series Installation Handbook

IPVK/6296 Series IP videokit
Index
Introduction .................................................................................................................................................................................... 2
System components and available versions ................................................................................................................................ 3
Art. 4533 IP speaker unit module .................................................................................................................................................. 5
Art. 4800 - 4800M Digital codelock module ................................................................................................................................. 9
4000 Series surface and flush mounting door station installation .......................................................................................... 12
Art. 6296 IP Videophone for VIDEX IP System ........................................................................................................................... 14
6200 Series Videophone wall mounting instructions ............................................................................................................... 31
Windows setup static IP address ................................................................................................................................................ 32
Installation diagrams ................................................................................................................................................................... 34
VX IP WIZARD Wizard configuration software for VIDEX IP System ........................................................................................ 43
INSTALLATION DIAGRAMS - NOTES AND SUGGESTIONS
• All diagrams refer to all kits versions: flush or surface, colour or black & white.
• Dashed connections refer to optional connections ("Local bell", "Push to exit" & "Door monitor").
• Some diagrams show how to connect a 12Vdc electric lock: these directions are suitable for all diagrams in this manual.
• Each time a setting is changed on a videophone (address, extension, number of rings etc.), the videophone must be disconnected from
the relevant connection board then after a few seconds reconnected again to allow the recognizing of the new setting.
• All diagrams shown are valid for systems with surface or flush mount door station.
• To install this equipment are required expertises in the field of information and networking technologies.
DECLETION OF RESPONSIBILITY
This manual has been written and revised carefully. The instructions and the descriptions which are included in it are referred to
VIDEX parts and are correct at the time of print. However, subsequent VIDEX parts and manuals, can be subject to changes without
notice. VIDEX Electronics S.p.A. cannot be held responsible for damages caused directly or indirectly by errors, omissions or discrep-
ancies between the VIDEX parts and the Manual.
WE RECOMMEND
This equipment is installed by a Competent Electrician, Security or Communications Engineer
IPVK/6296 Series - Installation handbook
- 2 -
66550062-EN - V 1.1 - 31/05/18
