Videx ESVK/6388 Series Installation Handbook
  1. Manuals
  2. Brands
  3. Videx Manuals
  4. Intercom System
  5. ESVK/6388 Series
  6. Installation handbook
Videx ESVK/6388 Series Installation Handbook

Videx ESVK/6388 Series Installation Handbook

2 wire bus one way, two way videokit
Hide thumbs Also See for ESVK/6388 Series:

Advertisement

Quick Links

Download this manual
VIDEOKIT
ESVK/6388 SERIES
"2 Wire" bus one way, two way videokit
ESVK
ESVKX
ESVKC
66550033-EN - V4.0 - 15/02/19
Installation handbook
6388
We recommend
This equipment is installed by a
Competent Electrician, Security or
Communications Engineer.
Rev.0.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ESVK/6388 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Videx ESVK/6388 Series

Summary of Contents for Videx ESVK/6388 Series

  • Page 1 VIDEOKIT Rev.0.1 ESVK/6388 SERIES “2 Wire” bus one way, two way videokit ESVK ESVKX ESVKC 6388 Installation handbook We recommend 66550033-EN - V4.0 - 15/02/19 This equipment is installed by a Competent Electrician, Security or Communications Engineer.

  • Page 2: Table Of Contents

    This manual has been written and revised carefully. The instructions and the descriptions which are included in it are referring to VIDEX parts and are correct at the time of print. However, subsequent VIDEX parts and manuals, can be subject to changes without notice.

  • Page 3: System Components And Available Versions

    ESVK/6388 Series “2 wire Bus” videokit System components and available versions ESVK/6388 Colour videokit. OUTDOOR INDOOR STATION STATION Videomonitor 135,0 45,0 22,7 Art. 6388 pag. 18 Camera unit Art. 4333 pag. 8 ACCESSORIES Power supply Art. 2321 pag. 23 15,7 43,8 120,0 Flush...
  • Page 4 ESVK/6388 Series “2 wire Bus” videokit System components and available versions ESVKX/6388 Colour videokit with embended proximity key reader. OUTDOOR INDOOR STATION STATION Videomonitor 135,0 45,0 22,7 Art. 6388 pag. 18 Camera unit Art. 4333X pag. 8 ACCESSORIES Power supply Art. 2321 pag. 23...
  • Page 5 ESVK/6388 Series “2 wire Bus” videokit System components and available versions ESVKC/6388 Colour videokit plus a codelock module. OUTDOOR INDOOR STATION STATION 135,0 45,0 24,0 51,0 Videomonitor Art. 6388 pag. 18 Camera unit Art. 4333 pag. 8 ACCESSORIES Power supply Art. 2321 Codelock pag.

  • Page 6: General Directions For Installation

    10 Ohms and can be calculated from point to point. The capac- itance of the cable must not exceed 40nF and is an accumulation of all lengths and branches of the cable. For example: Videx CM2 cable can be used for a maximum distance of 200m from door station to power supply and another 200m from power supply to videophone (400 meters) but this distance may be reduced if the maximum capacitance is reached first.
  • Page 7 ESVK/6388 Series “2 wire Bus” videokit General directions for installation CABLES LENGTH Art.KRV86 Art.3686 Art.317N Art.6286 Art.SL5488N Using Cable CM2 - Usando Cavo CM2 Art.2321 = Max 200m Using Cable CM2 - Usando Cavo CM2 = Max 200m = Max 200m...
  • Page 8 ESVK/6388 Series “2 wire Bus” videokit Art. 4333/4333X Rev.0.1 Speaker unit module with built-in functional to digital interface Balance 4333-0 4333-1 4333-2 4333X-0 4333X-1 4333X-2 Made in Italy STEEL HIGH BRASS MATTE 1 2 3 4 5 6 7 8 Fig. 1 Fig.
  • Page 9 ESVK/6388 Series “2 wire Bus” videokit Art. 4333/4333X Speaker unit module with built-in functional to digital interface FRONT LEDS SIGNALLING DESCRIPTION When illuminated, indicates that it is not possible to make a call because a call or a conversation is in progress (from the outdoor station from which you are calling or from another outdoor station on systems with multiple entranc- es).

  • Page 10: Art. 4333/4333X Speaker Unit Module With Built-In Functional To Digital Interface

    ESVK/6388 Series “2 wire Bus” videokit Art. 4333/4333X Speaker unit module with built-in functional to digital interface PROGRAMMING TAGS (FOR ART. 4333X) MASTER TAG The external module is supplied with a master tag. The master tag is programmed in-factory, it is white to easily stand out. This tag enables user tags to be programmed or cleared.
  • Page 11 ESVK/6388 Series “2 wire Bus” videokit Art. 4333/4333X Speaker unit module with built-in functional to digital interface REPROGRAMMING A MASTER TAGS If the master tag is lost or damaged, a new one can be programmed using the following procedure: 1. Switch off the power.
  • Page 12 ESVK/6388 Series “2 wire Bus” videokit Art. 4333/4333X Speaker unit module with built-in functional to digital interface ADHESIVE GASKET PLACEMENT seal as shown in Fig. 5. Apply the ANTI-TAMPERING LOCKS FIXING as shown in Fig. 6. Fit the anti-tampering locks Fig. 5 Fig.
  • Page 13 GENERAL DIRECTIONS FOR INSTALLATION In order to achieve the best results from the schematics described it is necessary to install only original VIDEX equipment, strictly keeping to the items indicated on each schematic and follow these General Directions for Installation: •...
  • Page 14 ESVK/6388 Series “2 wire Bus” videokit Art. 4800M Digital codelock module BUILT-IN RELAYS – BACK EMF PROTECTION The Art. 4800M includes selectable back EMF protection on the relays. The jumpers marked MOV (One jumper for each relay) are used to select the protection type. When using a fail secure lock with connections C & NO the jumper should be in the NO position. When using a fail open lock with connections C &...

  • Page 15: Art. 4800 - 4800M Digital Codelock Module

    ESVK/6388 Series “2 wire Bus” videokit Art. 4800M Digital codelock module ADHESIVE GASKET PLACEMENT seal as shown in Fig. 2. Apply the ANTI-TAMPERING LOCKS FIXING as shown in Fig. 3. Fit the anti-tampering locks Fig. 2 Fig. 3 CLEANING OF THE PLATE CONNECTION TERMINALS SIGNALS Use a clean and soft cloth.
  • Page 16 ESVK/6388 Series “2 wire Bus” videokit 4000 Series Surface and flush mounting door station installation EXAMPLE: INSTALLING A FOUR MODULE OUTDOOR STATION fig. 1 fig. 2 fig. 3 fig. 4 fig. 5 fig. 6 fig. 7 fig. 8 fig. 9 fig.

  • Page 17: Series Surface And Flush Mounting Door Station Installation

    ESVK/6388 Series “2 wire Bus” videokit 4000 Series Surface and flush mounting door station installation INSTALLING A SURFACE MOUNT DOOR STATION 1. Place the surface box against the wall (165-170cm between the top of the box and the floor level as shown in Fig. 1) and mark the fixing holes for the wall plugs and the hole for the cables (fig. 2).
  • Page 18 ESVK/6388 Series “2 wire Bus” videokit Art. 6388 3.5" hands free colour display digital videophone R01A 27 mm 102 mm DPSW2 DPSW1 COLOUR CONTR Fig. 1 Front Fig. 2 Back DESCRIPTION LEGEND An intelligent hands free videophone using 3.5” full colour ac- Speech volume control tive matrix LCD monitor for VX2300.
  • Page 19 ESVK/6388 Series “2 wire Bus” videokit Art. 6388 3.5" hands free colour display digital videophone PUSH BUTTONS Answerpush button On an incoming call, operation of this button allows the user to answer and converse with the visitor. The relevant LED will illuminate.
  • Page 20 ESVK/6388 Series “2 wire Bus” videokit Art. 6388 3.5" hands free colour display digital videophone PRIVACY DURATION • Keep pressed the button until the two LEDs are switched on. • Press the button for the number of times corresponding to the required privacy duration to set. Each time the button is pressed, the duration is increased by 15 minutes: i.e.

  • Page 21: Art. 6388 3.5" Colour Display Videophone

    ESVK/6388 Series “2 wire Bus” videokit Art. 6388 3.5" colour display videophone SLAVE MODE - SW2.4 This set up concerns the answering mode of the video monitor when there is more than one unit (max 4) in the same apartment. OFF (default) = during a call, only the video monitor with extension 1 (master) will show the video. ON = the...
  • Page 22 ESVK/6388 Series “2 wire Bus” videokit 6300 Series Wall mounting instructions Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 Fig. 7 1. In order to install the videophone, it is necessary to remove the cover, which contains all the electronics, from the base: then rotate clockwise until you listen a “CLICK!”.
  • Page 23 ESVK/6388 Series “2 wire Bus” videokit Art. 2321-2321/P Power supplies for VX2300 Art.2321 157,5 Fig. 1 Fig. 2 DESCRIPTION CONNECTION TERMINALS AND JUMPERS These two power supplies are specifically designed for the Mains input VX2300 digital system. The Art.  2321 can be used for systems ~230V with 1 entrance up to 20 users while the Art. 2321/P is for sys-...

  • Page 24: Art. 2322 Power Supply Converter From Bus Line To 12 Vdc

    ESVK/6388 Series “2 wire Bus” videokit Art. 2322 Power supply converter from BUS line to 12 Vdc Art.2322 Fig. 1 Fig. 2 DESCRITPION When this unit is connected to the BUS line it generates a +12Vdc – 100mA power source. This unit can be used to supply peripher- als such as the Art. 4800 or Art. 4800M without the need for an additional power supply.
  • Page 25 ESVK/6388 Series “2 wire Bus” videokit Art. 125 Call expansion module DESCRITPION This module must be used in combination with speaker units Art. 4333 with firmware release 2.0 or higher. The module, in com- bination with standard 4000 series button expansion modules (Art. 4842, Art. 4843, Art. 4844 and Art. 4845), allows to add up to 5 call buttons to the call buttons built-in the speaker unit to reach a maximum of 7 call buttons.

  • Page 26: Art. 125 Call Expansion Module

    ESVK/6388 Series “2 wire Bus” videokit Art. 125 Call expansion module Connect to “PTE” terminal of Art. 4333 Connect to “GND” terminal ofArt. 4333 Black BALANCE Connect to “1C” terminal of Art. 4842, Art. 4843, Art. 4844 or Art. 4845 Connect to terminal “1” of the button expansion module Connect to terminal “2”...
  • Page 27 )power off then power on). 12Vac Title: Data creazione: Foglio 17/02/2017 Titolo: Data modifica: 20/02/2017 Videx Electronics S.p.A. Notes: Autore: Roberto Gambini Via del Lavoro 1, 63846 Monte Giberto )FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 esvk-63h-001.dwg www.videx.it - info@videx.it...
  • Page 28 )power off then power on). 12Vac Title: Data creazione: Foglio 17/02/2017 Titolo: Data modifica: 20/06/2018 Videx Electronics S.p.A. Notes: Autore: Roberto Gambini Via del Lavoro 1, 63846 Monte Giberto )FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 esvk-63h-002.dwg www.videx.it - info@videx.it...
  • Page 29 )power off then power on). Title: Data creazione: Foglio 17/02/2017 Titolo: Data modifica: 20/02/2017 Videx Electronics S.p.A. Notes: Autore: Roberto Gambini Via del Lavoro 1, 63846 Monte Giberto )FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 esvk-63h-003.dwg www.videx.it - info@videx.it...
  • Page 30 )power off then power on). Title: Data creazione: Foglio 17/02/2017 Titolo: Data modifica: 20/02/2017 Videx Electronics S.p.A. Notes: Autore: Roberto Gambini Via del Lavoro 1, 63846 Monte Giberto )FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 esvk-63h-004.dwg...
  • Page 31 Exit 12Vac Title: Data creazione: Foglio 17/02/2017 Titolo: Data modifica: 20/02/2017 Videx Electronics S.p.A. Notes: Autore: Roberto Gambini Via del Lavoro 1, 63846 Monte Giberto )FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 esvk-63h-005.dwg www.videx.it - info@videx.it - 31 - 66550033-EN - V4.0 - 15/02/19...
  • Page 32 (power off then power on). Title: Data creazione: Foglio 20/02/2017 Titolo: Data modifica: 20/06/2018 Videx Electronics S.p.A. Notes: Autore: Roberto Gambini Via del Lavoro 1, 63846 Monte Giberto (FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 esvk-63h-006.dwg...
  • Page 33 Local Bell Local Bell Local Bell Term. OFF Term. OFF Term. ON Term. ON ART.6388 ART.6388 Extension N. Extension N. Videophone: Videophone: BUS OUT 1 BUS OUT 2 BUS OUT 3 BUS OUT 4 Close Close Close Close Open Open Open Open AMPLIFICATION...
  • Page 34 Art.125 Art.125 Title: Data creazione: Foglio 11/12/2017 Titolo: Data modifica: 11/12/2017 Videx Electronics S.p.A. Notes: Autore: Marco Rongoni Via del Lavoro 1, 63846 Monte Giberto (FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 esvk-63h-007.dwg www.videx.it - info@videx.it - 34 - 66550033-EN - V4.0 - 15/02/19...
  • Page 35 Local Bell Local Bell Term. OFF Term. ON ART.6388 Extension N. Videophone: BUS OUT 1 BUS OUT 2 BUS OUT 3 BUS OUT 4 Close Close Close Close Open Open Open Open AMPLIFICATION BUS LINE TERMINATION Art.317N Local Bell Local Bell Local Bell Term.
  • Page 36 (power off then power on). Title: Data creazione: Foglio 09/04/2018 Titolo: Data modifica: 20/06/2018 Videx Electronics S.p.A. Notes: Autore: Roberto Gambini Via del Lavoro 1, 63846 Monte Giberto (FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 esvk-63h-007a.dwg...
  • Page 37 Local Bell Local Bell Local Bell Term. OFF Term. OFF Term. ON Term. ON ART.6388 ART.6388 Extension N. Extension N. Videophone: Videophone: BUS OUT 1 BUS OUT 2 BUS OUT 3 BUS OUT 4 Close Close Close Close Open Open Open Open AMPLIFICATION...
  • Page 38 Local Bell Local Bell Local Bell Term. OFF Term. OFF Term. ON Term. ON ART.6388 ART.6388 Extension N. Extension N. Videophone: Videophone: BUS OUT 1 BUS OUT 2 BUS OUT 3 BUS OUT 4 Close Close Close Close Open Open Open Open AMPLIFICATION...
  • Page 39 Local Bell Local Bell Local Bell Term. OFF Term. OFF Term. ON Term. ON ART.6388 ART.6388 Extension N. Extension N. Videophone: Videophone: BUS OUT 1 BUS OUT 2 BUS OUT 3 BUS OUT 4 Close Close Close Close Open Open Open Open AMPLIFICATION...
  • Page 40 (power off then power on). Title: Data creazione: Foglio 09/04/2018 Titolo: Data modifica: 13/04/2018 Videx Electronics S.p.A. Notes: Autore: Roberto Gambini Via del Lavoro 1, 63846 Monte Giberto (FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 esvk-63h-008.dwg...
  • Page 41 Local Bell Local Bell Local Bell Term. OFF Term. OFF Term. ON Term. ON ART.6388 ART.6388 Extension N. Extension N. Videophone: Videophone: BUS OUT 1 BUS OUT 2 BUS OUT 3 BUS OUT 4 Close Close Close Close Open Open Open Open AMPLIFICATION...
  • Page 42 Local Bell Local Bell Local Bell Term. OFF Term. OFF Term. ON Term. ON ART.6388 ART.6388 Extension N. Extension N. Videophone: Videophone: BUS OUT 1 BUS OUT 2 BUS OUT 3 BUS OUT 4 Close Close Close Close Open Open Open Open AMPLIFICATION...
  • Page 43 DISPOSAL In accordance with the Legislative Decree no. 49 of 14 March 2014 “Implementation of the Directive 2012/19/EU on waste electrical and electronic equipment (WEEE)”. The crossed-out bin symbol on the equipment or on the packaging indicates that when the product reaches the end of its lifetime, it must be collected separately from mixed municipal waste.
  • Page 44 MANUFACTURER VIDEX ELECTRONICS S.P.A. FABBRICANTE Via del Lavoro, 1 FABRICANT 63846 Monte Giberto (FM) Italy FABRICANTE Tel (+39) 0734 631669 FABRIKANT Fax (+39) 0734 632475 ‫الشركة المص ن ِّ عة‬ www.videx.it - info@videx.it CUSTOMER SUPPORT VIDEX ELECTRONICS S.P.A. UK Customers only: SUPPORTO CLIENTI www.videx.it - technical@videx.it...
