VIDEOKIT ESVK/6286 SERIES “2 Wire” bus one way, two way videokit ESVK Rev.0.1 ESVKX Rev.0.1 ESVKC Rev.0.2 6286 Installation handbook We recommend 66550032-EN - V5.0 - 31/10/19 This equipment is installed by a Competent Electrician, Security or Communications Engineer.
Page 2
This manual has been written and revised carefully. The instructions and the descriptions which are included in it are referring to VIDEX parts and are correct at the time of print. However, subsequent VIDEX parts and manuals, can be subject to changes without notice.
Page 3
ESVK/6286 Series “2 wire Bus” videokit System components and available versions ESVK/6286 Colour videokit. OUTDOOR INDOOR STATION STATION Videophone 135,0 45,0 22,7 Art. 6286 pag. 19 Camera unit Art. 4333 pag. 8 ACCESSORIES Power supply Art. 2321 15,7 pag. 24 43,8 120,0 Flush Surface Mounting Mounting...
Page 4
ESVK/6286 Series “2 wire Bus” videokit System components and available versions ESVKX/6286 Colour videokit with embended proximity key reader. OUTDOOR INDOOR STATION STATION Videophone 135,0 45,0 22,7 Art. 6286 pag. 19 Camera unit Art. 4333X pag. 8 ACCESSORIES Power supply Art. 2321 pag. 24 15,7 43,8 Card format fob...
Page 5
ESVK/6286 Series “2 wire Bus” videokit System components and available versions ESVKC/6286 Colour videokit plus a codelock module. OUTDOOR INDOOR STATION STATION Videophone 135,0 45,0 22,7 Art. 6286 pag. 19 Camera unit Art. 4333 pag. 8 ACCESSORIES Power supply Art. 2321 Codelock pag. 24 unit Art. 4901 pag.
Page 6
10 Ohms and can be calculated from point to point. The capac- itance of the cable must not exceed 40nF and is an accumulation of all lengths and branches of the cable. For example: Videx CM2 cable can be used for a maximum distance of 200m from door station to power supply and another 200m from power supply to videophone (400 meters) but this distance may be reduced if the maximum capacitance is reached first.
Page 7
A+B+C+D+E+F = Max 400m Title: Data creazione: Foglio 29/05/2019 Titolo: Data modifica: 29/05/2019 Videx Electronics S.p.A. Notes: Autore: Marco Rongoni Via del Lavoro 1, 63846 Monte Giberto (FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 vx2300cla.dwg www.videx.it - info@videx.it...
Page 8
ESVK/6286 Series “2 wire Bus” videokit Art. 4333/4333X Rev.0.1 Speaker unit module with built-in functional to digital interface Balance 4333-0 4333-1 4333-2 4333X-0 4333X-1 4333X-2 Made in Italy STEEL HIGH BRASS MATTE 1 2 3 4 5 6 7 8 Fig. 1 Fig.
Page 9
ESVK/6286 Series “2 wire Bus” videokit Art. 4333/4333X Speaker unit module with built-in functional to digital interface FRONT LEDS SIGNALLING DESCRIPTION When illuminated, indicates that it is not possible to make a call because a call or a conversation is in progress (from the outdoor station from which you are calling or from another outdoor station on systems with multiple entranc- es).
Page 10
ESVK/6286 Series “2 wire Bus” videokit Art. 4333/4333X Speaker unit module with built-in functional to digital interface PROGRAMMING TAGS (FOR ART. 4333X) MASTER TAG The external module is supplied with a master tag. The master tag is programmed in-factory, it is white to easily stand out. This tag enables user tags to be programmed or cleared.
Page 11
ESVK/6286 Series “2 wire Bus” videokit Art. 4333/4333X Speaker unit module with built-in functional to digital interface REPROGRAMMING A MASTER TAGS If the master tag is lost or damaged, a new one can be programmed using the following procedure: 1. Switch off the power. 2.
Page 12
ESVK/6286 Series “2 wire Bus” videokit Art. 4333/4333X Speaker unit module with built-in functional to digital interface ADHESIVE GASKET PLACEMENT seal as shown in Fig. 5. Apply the ANTI-TAMPERING LOCKS FIXING as shown in Fig. 6. Fit the anti-tampering locks Fig. 5 Fig.
Page 13
GENERAL DIRECTIONS FOR INSTALLATION In order to achieve the best results from the schematics described it is necessary to install only original VIDEX equipment, strictly keeping to the items indicated on each schematic and follow these General Directions for Installation: •...
Page 14
ESVK/6286 Series “2 wire Bus” videokit Art. 4901 Digital codelock module LOCK RELEASE BACK EMF PROTECTION A varistor must be fi tted across the terminals on AC lock release (Fig.1A) and a diode must be fi tted across the terminals on a DC lock release (Fig.1B) to suppress back EMF voltages.
Page 15
ESVK/6286 Series “2 wire Bus” videokit Art. 4901 Digital codelock module PROGRAMMING MODE 1 (DEFAULT MODE, JPL = A) PROGRAMMING MODE 2 Follow the steps below to set the codelock to mode 1: Follow the steps below to set the codelock to mode 2: 1.
Page 16
ESVK/6286 Series “2 wire Bus” videokit Art. 4901 Digital codelock module OPERATION • Type in the programmed code and press ENTER; • If the code is correct, the green LED will illuminate for approx. 2 seconds and the relay relevant to the code will operate for the programmed time;...
Page 17
ESVK/6286 Series “2 wire Bus” videokit 4000 Series Surface and flush mounting door station installation EXAMPLE: INSTALLING A FOUR MODULE OUTDOOR STATION fig. 1 fig. 2 fig. 3 fig. 4 fig. 5 fig. 6 fig. 7 fig. 8 fig. 9 fig.
Page 18
ESVK/6286 Series “2 wire Bus” videokit 4000 Series Surface and flush mounting door station installation INSTALLING A SURFACE MOUNT DOOR STATION 1. Place the surface box against the wall (165-170cm between the top of the box and the floor level as shown in Fig. 1) and mark the fixing holes for the wall plugs and the hole for the cables (fig. 2).
Page 19
ESVK/6286 Series “2 wire Bus” videokit Art. 6286 3.5" colour display videophone R01A 27 mm 144 mm PT3 PT2 Fig. 1 Front Fig. 2 Back DESCRIPTION LEGEND An intelligent Videophone using 3.5” full colour active matrix Connection terminals LCD monitor for VX2300. Including 4 buttons “service”, “privacy/ Bus termination switch bus relay activation”, “door-open/intercommunicating call”...
Page 20
ESVK/6286 Series “2 wire Bus” videokit Art. 6286 3.5" colour display videophone LEDS CONTROLS Call tone volume control Privacy on LED (3 levels). It illuminates when the privacy service is enabled. Brightness control Generic use LED (sliding wheel). It is controlled from the terminals +DOL and –DOL. Nor- Colour intensity control trimmer mally used to signal the door status (open or closed).
Page 21
ESVK/6286 Series “2 wire Bus” videokit Art. 6286 3.5" colour display videophone VIDEOPHONE ADDRESS – SW1.1..7 The table below shows how to set the address of the videophone. Considering that ON = 1 and OFF = 0, multiply each digit for the relevant decimal weight then sum values obtained to get the address: E.g. as highlighted in 1 2 3 4 5 6 7 the table OFF, ON, OFF, OFF, ON, OFF, ON in binary is equal to 0100101 then multiplying each digit for the rele- SW1.1..7...
Page 22
ESVK/6286 Series “2 wire Bus” videokit Art. 6286 3.5" colour display videophone CONNECTION TERMINALS SIGNALS SPECIFICATION Housing/Mounting: 6200 Series Videophones / surface BUS1 Bus input mount BUS2 Bus input Push buttons: Yes, 4 Ground Programming: Yes, carried out by the buttons and +12Vdc power supply input (Art. ...
Page 23
ESVK/6286 Series “2 wire Bus” videokit 6200 Series Videophone wall mounting instructions Fig. 1 Fig. 2 Fig. 3 Fig. 5 Fig. 4 Fig. 6 Fig. 7 1. In order to install the videophone, it is necessary to remove the cover, which contains all the electronics, from the base: firstly disconnect the handset from the videophone (by removing its plug from the videophone) then insert a 5.5mm flat screw driv- er into the clip then rotate clockwise until you listen a “CLICK!”.
Page 24
ESVK/6286 Series “2 wire Bus” videokit Art. 2321-2321/P Power supplies for VX2300 Art.2321 157,5 Fig. 1 Fig. 2 DESCRIPTION CONNECTION TERMINALS AND JUMPERS These two power supplies are specifically designed for the Mains input VX2300 digital system. The Art. 2321 can be used for systems ~230V with 1 entrance up to 20 users while the Art. 2321/P is for sys- BUS +...
Page 25
ESVK/6286 Series “2 wire Bus” videokit Art. 2322 Power supply converter from BUS line to 12 Vdc Art.2322 Fig. 1 Fig. 2 DESCRITPION When this unit is connected to the BUS line it generates a +12Vdc – 100mA power source. This unit can be used to supply peripher- als such as the Art. 4800 or Art. 4800M without the need for an additional power supply.
Page 26
ESVK/6286 Series “2 wire Bus” videokit Art. 4342 .. 4345 Single row button expansion modules 4342 4343 4344 Made in Italy 4345 STEEL HIGH BRASS MATTE ADDRESSING TABLE EB EB1 EB EB1 EB EB2 EB EB2 (EB1, EB2, SW7 Art.4333) SW7=OFF SW7=ON SW7=OFF SW7=ON...
Page 27
ESVK/6286 Series “2 wire Bus” videokit Art. 4342 .. 4345 Single row button expansion modules HOW TO REMOVE/INSERT THE CARD NAME HOLDER • To avoid damage to the module front plate, mask the side that will be in contact with the screwdriver blade; •...
Page 28
)power off then power on). 12Vac Title: Data creazione: Foglio 02/02/2017 Titolo: Data modifica: 06/02/2017 Videx Electronics S.p.A. Notes: Autore: Marco Rongoni Via del Lavoro 1, 63020 Monte Giberto )AP) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 esvk-62h-001.dwg www.videx.it - info@videx.it...
Page 29
)power off then power on). 12Vac Title: Data creazione: Foglio 02/02/2017 Titolo: Data modifica: 06/02/2017 Videx Electronics S.p.A. Notes: Autore: Marco Rongoni Via del Lavoro 1, 63020 Monte Giberto )AP) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 esvk-62h-002.dwg www.videx.it - info@videx.it...
Page 34
(power off then power on). Title: Data creazione: Foglio 03/02/2017 Titolo: Data modifica: 01/03/2017 Videx Electronics S.p.A. Notes: Autore: Marco Rongoni Via del Lavoro 1, 63846 Monte Giberto (FM) Note: Cod.File: Phone: +39 0734 631669 - Fax +39 0734 631669 esvk-62h-006.dwg...
Page 35
Local Bell Local Bell ART.6286 ART.6286 Extension N. Extension N. Videophone: Videophone: BUS OUT 1 BUS OUT 2 BUS OUT 3 BUS OUT 4 Close Close Close Close Open Open Open Open AMPLIFICATION BUS LINE TERMINATION Art.317N Local Bell Local Bell ART.6286 ART.6286 Extension N.
Page 39
DISPOSAL In accordance with the Legislative Decree no. 49 of 14 March 2014 “Implementation of the Directive 2012/19/EU on waste electrical and electronic equipment (WEEE)”. The crossed-out bin symbol on the equipment or on the packaging indicates that when the product reaches the end of its lifetime, it must be collected separately from mixed municipal waste.
Page 40
MANUFACTURER VIDEX ELECTRONICS S.P.A. FABBRICANTE Via del Lavoro, 1 FABRICANT 63846 Monte Giberto (FM) Italy FABRICANTE Tel (+39) 0734 631669 FABRIKANT Fax (+39) 0734 632475 الشركة المص ن ِّ عة www.videx.it - info@videx.it CUSTOMER SUPPORT VIDEX ELECTRONICS S.P.A. UK Customers only: SUPPORTO CLIENTI www.videx.it - technical@videx.it...
