6200 Series
Art. 6296
3.5" touchscreen videophone for IPure system
27 mm
A
B
C
Fig. 1 Front
DESCRIPTION
3.5" TFT high-resolution LCD monitor, OSD capacitive touch
screen, 4 buttons con gurable for functions: door open, inter-
com call, auto start, camera switching, timed privacy service.
12Vdc or PoE power supply.
2 inputs / 2 outputs.
Wall mounted, white or black nish.
VIDEOPHONE INITIALISATION
If powering on the videophone (through a POE switch/router or
an external power supply unit) the display shows the message
"DEVICE NOT INITIALISED", use the con guration software for
the VIDEX IP system (Videx IP Wizard.exe) to setup the device
and the system.
LEDS
Privacy on LED
It illuminates when the privacy service is enabled.
Service LED
It ashes showly if the gateway is not found.
If turned on, the device has failed to register with the
con gured SIP server.
Missed call LED
C
It ashes showly if there is a missed call.
Art. 6296 - Installation instructions
144 mm
F
D
E
G
Fig. 2 Inside
LEGEND
A
Touchscreen display
B
Tactile programmable
buttons and LED's
C
Missed call LED
D
Call tone volume control
E
Brightness control
F
Handset
To download the programming software
VX IP Wizard and obtain the latest rmware
and manuals please visit the following web-
site and register
https://service.videx.it/
CONTROLS
Call tone volume control
3 level switch (it controls also the local bell volume).
Brightness control
Sliding wheel.
Microphone volume trimmer
It increases the volume from the handset to the door
panel loudspeaker.
- 1 -
H
I
E
D
G
Connection terminals
H
Ethernet connector
I
Microphone volume trim-
mer
I
66251115 - V5.0 - 30/09/21
