Parts List Pneumatic - TE Connectivity AT-SC Operating Instructions Manual

528050-1
17.4

Parts List Pneumatic

Item-No. Pcs
10 2
11 1
12 1
13/a 3
13/b 1
13/b 1
14 1
15 1
16 1
18 1
19 1
20 1
21 4
22 1
24 1
25 1
26 2
27 1
28 2
29 1
30 1
32 3
35 2
37 1
38 2
39 1
40
41 1
42 1
43 1
44 1
45 1
46 1
47 1
48 1
TE-P/N Spare Part
6-523781-9 X
7-523781-5 X
7-523781-1 X
7-523781-3 X
7-523781-3 X
1-523796-1 X
6-523791-7 X
1-523796-2 X
1-523796-3 X
1-523796-4 X
7-523781-2 X
7-523781-4 X
1-523796-5 X
6-523791-0 X
3-523796-0 X
6-523791-3 X
1-523796-6 X
2-523796-8 X
2-523796-9 X
1-523796-7 X
6-523791-9 X
7-523781-0 X
523796-6 X
6-523791-3 X
1-523796-8 X
1-523796-9 X
2-523796-0 X
2-523796-1 X
2-523796-2 X
6-523791-8 X
2-523796-3 X
2-523796-4 X
2-523796-5 X
2-523796-6 X
Page 66 / 101
Description
Cylinder 63/50
5/2-Pneum. Valve K52DP218
Oder-Valve 4mm OR42
Micro-Switch Kuhnke 72.020
Return switch 72.010
Switch RELEASE 72.010
Connector J5PK6-4
T-Connector JPK 8-8-6
Plug 6mm FNPK6
Quick Discharge Valve 1/8" 1VSR
Muffler 1/8" PSY18
Hose-Nipple WPB8
Hose-Nipple WPB6
Angle Hose-Stem C64SPK8-1/8"
Hose-Nipple F4PB8-1/8"
Angle Hose-Stem C64PMK6-1/8"
Angle Hose-Stem C64PMK4-1/8"
Angle Hose-Stem C63SPK8-1/4"
Angle Hose-Stem C63SPK6-1/4"
Y-Connector 6mm YJPMK6
Hose-Nipple YJ64PK8-1/8"
Connector TR2PK6-4
Muffler 1SCT
Cylinder ECQ2-B32-25D
Angle Hose-Stem C64SPK4-1/8"
Fine adjustment valve 1/8" VRF8
Hose-Nipple F4PMB4-1/8"
Manometer 0-6 bar
Fine adjustment valve ARS1020F-M5-06
Pressure governor AR10-M5H
Connector KJF 06-M5
Y-Connector 4mm YJPMK4
Female Connector G4PB4 1/8"
Angle
Angle T2ESPK8
Female Connector F28PMB6 M5
