528050-1
17.2
Parts List Exploded View Drawing
Item-No.
Pcs
TE P/N
1
1
5-523795-0
2
2
5-523795-1
3
1
5-523795-2
4
1
5-523795-3
5
1
5-523795-4
6
1
5-523795-5
7
2
5-523795-6
8
1
5-523795-7
9
1
5-523795-8
10
2
5-523795-9
11
1
6-523795-0
12
2
6-523795-1
13
2
1-523781-4
14
4
2-523781-8
15
1
6-523795-2
16
1
6-523795-3
17
1
1-523781-3
18
1
1-523781-2
19
1
2-523796-7
20
1
6-523795-4
21
1
6-523795-5
22
1
6-523795-6
23
1
6-523795-7
24
1
6-523795-8
25
1
6-523795-9
26
1
7-523795-0
27
1
7-523795-1
28
1
7-523795-2
29
1
7-523795-3
30
1
7-523795-4
31
1
1-523781-1
32
1
7-523795-5
33
1
1-523781-0
34
1
7-523795-6
35
1
7-523795-7
36
2
7-523795-8
37
1
7-523795-9
Spare Part
Description
Basic Plate 1296-03
Lever - 1296-06
Traverse Wave -1296-11
Joint Flange-1296-12
X
Front Panel Left-1296-14
X
Front Panel Right-1296-15
Side Panel 1296-01
End Switch Angle-1296-16
End Switch Flag-1296-17
Joint Wave-1296-18
Distance Ring -1296-19
Washer - 1296-28
Buffer-1296-29
X
Rework Cylinder Sleeve - 1296-34
Cylinder Plate-1296-02
X
Guide Pin - 1296-27
Pusher-1296-09 BA
Tappet 1296-21 SSC
Die Guidance- 1296-23
Threaded Pin - 1296-24
X
Cover Plate 1296-42 SSC
X
Back Board-1296-05 SSC
X
Manometer-Support Angle-1296-36 SSC
piston rod extension-1296-39 SSC
Cylinder Bearing-1296-40 SSC
X
Front Plate-1296-04 SSC
Pneumatic Lever-1296-41 SSC
Control Panel -1296-45 SSC
Valve Plate-1296-46 SSC
X
Covering Angle-1296-20 BA
Cover 1296-13SSC
Compression Lever-1296-07 BA
Slide Bearing-1296-08 BA
Twin Shaft-1296-33 BA
Spring Arm-1296-35 BA
Distance Tube-1296-38 BA
Carrier-1296-22 BA
Page 61 / 101
412-18876 Rev. G
ECOC: EGC0 ; LOC: AI
