Technical Description; Operators Guide - TE Connectivity AT-SC Operating Instructions Manual

528050-1
6

Technical Description

6.1

Operators Guide

17
16
Pos. Description
01 Pneum. Parallel Crimp Machine AT-SC
02 Adjustment Screw
03 Grease Nipple
04 Upper Holder for Die Adapter
05 Lower Holder for Die Adapter
06 Locking Screw (Height)
07 Locking Screw (Shaft)
08 Adapter for Dies
09 Crimping Die
10 Release Button
11 Counter
12 Air Gauge
13 Compressed Air Connections
14 Pre-load Speed
15 Pre-load Pressure
17 Pneum. Double Foot Pedal
18 Safety Cover for Foot Pedal
14
15
13
Fig. 6.01
10
Page 44 / 101
12
09
07
08
412-18876 Rev. G
01
02
11
03
04
05
06
Fig. 6.02
