9.1.14 ALM/SUP/TBL/BLDG AUDIBLE SIL (Buzzer Silence)

Flashes amber at a slow rate when the buzzer is silenced.

9.1.15 Pre Release

Flashes red at a fast rate, when the release timer is started turns off when the release timer
expires or the system is reset.
9.2

Menu Buttons

To use the menu buttons you will need to install the CFG-300 configuration tool. See 10.1
Using the CFG-300 Tool on page 48 31 for details.
Menu Button
Menu
M
Pressing
Button
Info
? When the system is off-normal, press
Button
Enter
Pressing this button to select a menu option or to confirm a menu operation.
Button
Cancel
To return to previous menu in the configuration or command mode.
X
Button
9.3

Switches and Common Indicators

The FR-320 Series panel is a six-zone panel with four output circuits. The circuits are
arranged in the following configuration:
Zone 1
Zone 2
Zone 3
Zone 4
Zone 5
Zone 6
Out 1
Out 2
Out 3
Out 4
9.3.1

Zone 1 to Zone 4

• Alarm LED (red) turns on steady when an alarm is detected
• Supervisory LED (amber)turns on steady when the circuit is active
• Trouble LED (amber)turns on at slow flash rate when in trouble or bypassed
9.3.2

Zone 5 and Zone 6

• Alarm LED & Trouble LEDThe zone type and LED behavior varies upon the
configuration. Steady when turned on.
M
and entering the passcode will allow you to enter the command menu.
Input circuit
Input circuit
Input circuit
Input circuit
Manual Release switches or Abort switches or individual switch
Manual Release switches or individual switch
NAC1
NAC2
Releasing circuit 1
Releasing circuit 2 or NAC3 in some applications
Indicators, Controls and Operations
? to display extra information of the event.
