Table 10 FR-320 Series Specifications (Continued)
FR-320 Series Fire Control Panel Chassis
Unfiltered supply
(full wave rectified)
Battery
Compliance

Table 11 FR-320 System Modules and Annunciators

FR-320
System Modules and Annunciators
RM-306 Relay Adder Module
Contact rating
Current consumption
ICAC-306 Input Class A Converter module
OCAC-304 Output Class A Converter Module
SRM-312
Smart Relay Module
Contact rating
Current consumption
RAM-208 8 Zone Remote Annunciator
102
Power limited / Unregulated / Special Application
1.7A Max, 21.3 VDC to 42.00 VDC
Minimum Load 5mA
Type
Charging capability
Protection
System Model
System Type
Type of Service
Type of Signalling
Applicable Standards
24VDC Gel Cell/Sealed lead acid – 10AH to 26AH
10AH to 26AH
10A on board (F1) slow blow micro fuse
FR-320 Series Control Unit - Fire Alarm, for
Releasing services
Local Auxiliary (using PR-300), Remote Protected
Premises Station (using PR-300 or FR-320-DR/DW).
Central Station Protected Premises (using FR-320-
DR/DW.) For ULC application also use PR-300 for
alternate communication path.
A, M, WF, SS
Non-Coded
NFPA 12, 12A, 12B, 12, 15, 16,70,72,2001, UL-864
Rev. 9, ULC S-524, ULC S-527-11
Must be connected to a listed power-limited
source of supply.
FormC/ 28VDC per contact / 1A resistive load
max, zoned
standby 0mA, alarm 80mA
standby: 0mA / alarm: 0mA
standby: 0mA / alarm: 0mA
Must be connected to a listed power-limited
source of supply
Contact rating FormC/ 28VDC per contact /
1A resistive load max, zoned
Current consumption standby 30mA / alarm
140mA
FormC/ 28VDC per contact / 1A resistive load
max, zoned
standby 30mA, alarm 140mA
Standby 35mA / alarm 90mA
Appendix E: Specifications
