I User Interface
The DeviceNet control card contains two
bi-color (green/red) LED's for each connector
hookup port, to indicate the state of the device
and network, respectively.
Module LED:
LD1 on VLT 2800 Dual colour
(Green/Red)
OFF
GREEN
Flashing GREEN
Flashing RED
RED
Flashing GREEN/RED
NETWORK LED:
VLT status
Network is non-
powered/not on-line
Network is on-line but
not connected
Network is on-line and
connected
Network has a
connection timeout
Network has a critical
link failure
12
Yellow FCD 300 STATUS LED
when selected as DeviceNet in
parameter 26
OFF
YELLOW
Flashing YELLOW
OFF
OFF
Flashing YELLOW
LD2 on VLT 2800 Dual
colour (Green/Red)
OFF
Flashing GREEN
GREEN
Flashing RED
RED
®
VLT 2800 / FCD 300 DeviceNet
VLT status
Device is OFF
Device is operational
Device is in standby
Device detects a recoverable fault
Device detects an unrecoverable
fault
Device is self testing
Green BUS LED on
FCD 300
OFF
Flashing GREEN
GREEN
OFF
OFF
MG.90.B2.02 - VLT is a registered Danfoss trade mark
VLT status
Network is non-
powered/not on-line
Network is on-line but
not connected
Network is on-line and
connected
Network has a
connection timeout
Network has a critical
link failure
