DeviceNet object classes

I Class Code 0x01
For Class Code 0x01, the following Identity Instance
Attributes have been implemented:
Attribute Access
1 Get
2 Get
3 Get
4 Get
5 Get
6 Get
7 Get
10 Get/Set
I Class Code 0x02
For Class Code 0x02, the following Message Router
Instance Attributes have been implemented:
Attribute Access
1 Get
I Class Code 0x03
For Class Code 0x03, the following DeviceNet
Objects have been implemented:
Attribute Access
1 Get/Set
2 Get/Set
3 Get/Set
5 Get
6 Get
7 Get
MG.90.B2.02 - VLT is a registered Danfoss trade mark
Name Datatype
Vendor USINT
Device Type UINT
Product Code UINT
Revision UINT
Status UINT
Serial number UDINT
Product Name String
Heartbeat USINT
Interval
Name Datatype
Number of USINT
classes
Name Datatype
MAC ID USINT
Baud Rate USINT
BOI BOOL
Allocate
Information
MAC ID Switch BOOL
changed
Baud Rate BOOL
switched from
last power up
®
VLT 2800 / FCD 300 DeviceNet
Min/Max Units
200 - 399 VLT 2800
400 - 499 FCD 300
Min/Max Units
Min/Max Units
0-63
0-2
0-1
0-1
Default Description
97 Danfoss Drives
Vendor Code
2 AC/DC Motor
See EDS File section
Software version on
VLT 2800/FCD 300
From VLT 2800/FCD
300
VLT 2800/FCD 300
Default Description
Default Description
63 Node adress
0 0 = 125
1 = 250
2 = 500
Bus-Off Interrupt
Only required
if predefined
Master/Slave is
implemented
0 The Node adress
Switch has changed
since the last
power-up/reset
0 Tha Baud Rate Switch
has changed since the
last power-up/reset
