I Class Code 0x29
For Class Code 0x29, the following Control Supervisory
Instance Attributes have been implemented:
Attribute Access
3 Get/Set
4 Get/Set
5 Get/Set
6 Get
7 Get
8 Get
9 Get
10 Get
12 Get/Set
13 Get
15 Get
16 Get/Set
AC drive profile is only available if selecting
Instance 20/70 or 21/71
MG.90.B2.02 - VLT is a registered Danfoss trade mark
Name Datatype
Run 1 Bool
Run 2 Bool
NetCtrl Bool
State USINT
Running 1 Bool
Running 2 Bool
Ready Bool
Fault Bool
Fault Rst Bool
Fault Code UINT
Crt From Net Bool
DN Fault Mode USINT
®
VLT 2800 / FCD 300 DeviceNet
Min/Max Default
0-1 Run Fwd, see note below
0-1 Run rev, see note below
0-1 1 0 = Local Control
1 = Control from Network
0-7 0 = Vendor Specific
1 = Startup
2 = Not ready
3 = Ready
4 = Enabled
5 = Stopping
6 = Fault Stop
7 = Fault
0-1 0 0 = Other State
1 = (Enable and Run 1) or
(Stopping and Running 1 ) or
(Fault stop and Running 1)
0-1 0 0 = Other State
1 = (Enable and Run 2) or
(Stopping and Running 2) or
(Fault stop and Running 2)
0-1 0 = Other State
1 = Ready or Enabled or Stopping
0-1 0 = No Faults Present
1 = Fault Occured (latched)
0-1 0 0 = No Action
0 →1 = Reset Fault
0-1 1 0 = Control is local
1 = Control is from Network
0-2 1 Action on loss of DeviceNet
0 = Fault + Stop
1 = Ignore (Warning Optional)
2 = Danfoss specific
Description
