I Class Code 0x04
For Class Code 0x04, the following Assembly Object
Instances have been implemented:
Attribute Access
3 Set
Attribute Access
20 Set
21 Set
70 Get
71 Get
100 Set
101 Set
150 Get
151 Get
I Class Code 0x05
For Class Code 0x05, the following Connection
Object Attributes have been implemented:
Instance 1 Attributes: Explicit Message Instance
Attribute Access
1
2
3
4
5
6
7
8
9 Get/Set
12
13
14
15
16
17
26
Name Datatype
Data ARRAY
Datasize
2 Words DeviceNet AC/DC Profile
2 Words DeviceNet AC/DC Profile
2 Words DeviceNet AC/DC Profile
2 Words DeviceNet AC/DC Profile
2 Words Danfoss specific, no PCD Words
4 Words Danfoss specific, 2 PCD Words
2 Words Danfoss specific, no PCD Words
4 Words Danfoss specific, 2 PCD Words
Name
Get State
Get Instance Type
Get Transport Class Trigger
Get Produced Connection ID
Get Consumed Connection ID
Get Initial Communication
Characteristics
Get Produced Connection size
Get Consumed Connection size
Expected Package
Get Watchdog timeout action
Get Produced Connection Path
Length
Get Produced Connection Path
Get Consumed Connection Path
Length
Get Consumed Connection Path
Get Production Inhibit Time
®
VLT 2800 / FCD 300 DeviceNet
Min/Max Units
Description
Datatype
USINT State of the object
USINT Indicates either I/O or Messages Connection
USINT Defines behaviour of the Connection
UINT CAN Identifier Field when the Connection transmits
UINT AN Identifier Field value that denotes message to
be received
USINT Defines the message group(s) across which
productions and consumptions associated with this
Connection occur
UINT Maximum number of bytes transmitted across this
Connection
UINT Maximum number of bytes received across this
Connection
UINT Defines timming associated with this Connection
USINT Defines how to handle Inactivity/Watchdog timeout
UINT Number of Bytes in the produced connection path
attribute
Array of USINT Specifies the Application Object(s) whose data is to
be produced by these Connection Objects
UINT Number of bytes in the consumed connection path
attribute
Array of USINT Specifies the Application object(s) that are to receive
the data consumed by this Connection object
UINT Defines minimum time between new data production.
This attribute is required for I/O Client connection
MG.90.B2.02 - VLT is a registered Danfoss trade mark
