Example, 0 - ± 10 Volt:
External reference signal =
Reference =
Configuration (parameter 100) =
Setting:
Parameter:
100
Configuration
308
Funct. of analogue input
309
Min. reference signal
310
Max. reference signal
203
Reference range
205
Max. reference
200
Output frequency range/direction
MG.90.B2.02 - VLT is a registered Danfoss trade mark
®
VLT
0 V (min) ± 10 V (max)
50 Hz ccw - 50 Hz cw
Speed control, open loop
Setting:
Speed control, open loop
Reference
Min.
Max.
Reference range
Both directions, 0-132 Hz
2800 / FCD 300 DeviceNet
Data value:
[0]
[1]
0 V
10 V
- Max - + Max [1]
50 Hz
[1]
63
