I FCD 300 Electrical connection
The DeviceNet bus connection can be performed
through a plug, that is to be mounted in the
FCD 300 housing (M16 gland hole) and wired
to the inside terminal strip.
Wiring list
M12 Circular connector Terminal strip
4
5
2
3
1
DeviceNet plug 175N2279
MG.90.B2.02 - VLT is a registered Danfoss trade mark
68
69
67
70
D
®
VLT 2800 / FCD 300 DeviceNet
Colour
White
Blue
Red
Black
Green
Function
Can high
Can low
+ 24 V
GND
Drain
11
